| Bale Chamber |
|
Belt Width |
7 in (18 cm)
|
|
Number Of Belts |
8 |
| Bale Size |
|
Bale Diameter - Max |
6 ft (2 m)
|
|
Bale Diameter - Min |
3 ft (1 m)
|
|
Bale Weight - Max |
2,401 lbs (1,089 kg)
|
|
Bale Weight - Min |
2,200 lbs (998 kg)
|
|
Bale Width |
5 ft (2 m)
|
| Baler Pickup |
|
Lift Type |
crank |
|
Number Of Bars |
4 |
|
Number Of Tines |
96 |
|
Overall Width |
6 ft (2 m)
|
|
Tine To Tine Width |
5 ft (2 m)
|
| Dimensions |
|
Overall Height |
9 ft (3 m)
|
|
Overall Length |
12 ft (4 m)
|
|
Overall Width |
9 ft (3 m)
|
|
Tractor Pto Power Required |
75 hp (56 kw)
|
|
Weight |
4,729 lbs (2,145 kg)
|
| Drive |
|
Maximum Drawbar Pull |
71,264 lbs (32,319 kg)
|
|
Maximum Travel Speed |
3 mph (5 kph)
|
| Engine |
|
Bore |
5 in (12 cm)
|
|
Displacement |
568 cu in (9,300 cu cm)
|
|
Engine Model |
Cat C9.3 (ATAAC) |
|
Gross Power |
319 hp (238 kw)
|
|
Maximum Torque |
1,052 lbs ft (1,426 nm)
|
|
Net Flywheel Power |
291 hp (217 kw)
|
|
Number Of Cylinders |
6 |
|
Rated Power |
296 hp (221 kw)
|
|
Rated Speed |
1,800 rpm |
|
Stroke |
6 in (15 cm)
|
| Hydraulic System |
|
Auxiliary Pump - Maximum Flow - Capacity |
29 gpm (108 lpm)
|
|
Auxiliary Pump - Maximum Flow - Factory Setting |
14 gpm (51 lpm)
|
|
Auxiliary Pump - Maximum Pressure - Capacity |
3,626 psi |
|
Auxiliary Pump - Maximum Pressure - Factory Setting |
1,500 psi |
|
General Forestry - Boom Cylinder - Bore |
6 in (15 cm)
|
|
General Forestry - Boom Cylinder - Stroke |
57 in (144 cm)
|
|
General Forestry - Bucket Cylinder - Bore |
6 in (15 cm)
|
|
General Forestry - Bucket Cylinder - Stroke |
45 in (115 cm)
|
|
General Forestry - Stick Cylinder - Bore |
7 in (17 cm)
|
|
General Forestry - Stick Cylinder - Stroke |
68 in (174 cm)
|
|
Log Loader - Boom Cylinder - Bore |
7 in (17 cm)
|
|
Log Loader - Boom Cylinder - Stroke |
53 in (134 cm)
|
|
Log Loader - Bottom Heel Cylinder - Bore |
6 in (15 cm)
|
|
Log Loader - Bottom Heel Cylinder - Stroke |
46 in (116 cm)
|
|
Log Loader - Stick Cylinder - Bore |
7 in (18 cm)
|
|
Log Loader - Stick Cylinder - Stroke |
65 in (166 cm)
|
|
Log Loader - Top Heel Cylinder - Bore |
6 in (16 cm)
|
|
Log Loader - Top Heel Cylinder - Stroke |
58 in (147 cm)
|
|
Main Pump System - Maximum Flow (2x) |
76 gpm (289 lpm)
|
|
Maximum Pressure - Implements |
5,076 psi |
|
Maximum Pressure - Swing - Dual |
4,550 psi |
|
Maximum Pressure - Swing - Single |
4,061 psi |
|
Pilot System - Maximum Flow |
7 gpm (26 lpm)
|
|
Pilot System - Maximum Pressure |
595 psi |
| Operating Specifications |
|
Maximum Drawbar Pull |
71,264 lbs (32,319 kg)
|
|
Maximum Speed High Range |
3 mph (5 kph)
|
|
Maximum Swing Speed - General Forestry |
10 rpm |
|
Maximum Swing Speed - Log Loader |
6 rpm |
|
Operator Height From Ground (Eye Level) - General Forestry Cab 0.48 M (18 In) Riser |
135 in (343 cm)
|
|
Operator Height From Ground (Eye Level) - Log Loader Cab 1.2 M (48 In) Riser |
165 in (419 cm)
|
|
Swing Torque - General Forestry |
84,024 lbs ft (113,920 nm)
|
|
Swing Torque - Log Loader |
109,560 lbs ft (148,541 nm)
|
| Service Refill Capacities |
|
Cooling System |
15 gal (56 l)
|
|
Engine Oil |
8 gal (31 l)
|
|
Final Drive - Each |
2 gal (8 l)
|
|
Fuel Tank Capacity - Main |
164 gal (620 l)
|
|
Fuel Tank Capacity - Rf |
153 gal (580 l)
|
|
Fuel Tank Capacity - Total |
317 gal (1,200 l)
|
|
Hydraulic System - Total |
100 gal (380 l)
|
|
Hydraulic Tank |
46 gal (175 l)
|
|
Swing Drive - General Forestry |
5 gal (19 l)
|
|
Swing Drive - Log Loader 2x |
5 gal (20 l)
|
| Standards |
|
Brakes |
ISO 10265:1998 ISO 11512:1995 |
|
Rops/Fops/Ops/Tops |
ISO 8083:1989 LEVEL I ISO 8083:1989 LEVEL II* |
| Track |
|
Number Of Carrier Rollers - Each Side |
2 |
|
Number Of Shoes - Each Side |
52 |
|
Number Of Track Rollers - Each Side |
10 |
| Undercarriage |
|
Ground Clearance |
3 ft (1 m)
|
|
Track Gauge |
10 ft (3 m)
|
|
Track Length |
18 ft (5 m)
|
|
Undercarriage Pitch |
9 in (22 cm)
|
|
Undercarriage Size |
345HD |
| Weights |
|
General Forestry |
95,204 lbs (43,176 kg)
|
|
Log Loader (O/U) |
106,479 lbs (48,290 kg)
|
|
Log Loader (U/U) |
106,128 lbs (48,131 kg)
|
| Wrapping System |
|
Twine Ball Capacity |
8 |
|
Twine Type |
electric |
