| Dimensions |
|
Dump Angle |
45 degrees |
|
Dump Height - Maximum |
102 in (259 cm)
|
|
Dump Reach |
39 in (100 cm)
|
|
Ground Clearance |
10 in (26 cm)
|
|
Height To Top Of Rops |
85 in (215 cm)
|
|
Hinge Pin Height, Maximum Height |
126 in (320 cm)
|
|
Length With Bucket |
12 ft (4 m)
|
|
Length With Out Bucket |
10 ft (3 m)
|
|
Turning Radius |
7 ft (2 m)
|
|
Width Over Tracks |
1 ft (0 m)
|
| Drive |
|
Maximum Drawbar Pull |
55,977 lbs (25,391 kg)
|
|
Maximum Travel Speed |
3 mph (5 kph)
|
| Engine |
|
Aspiration |
Turbocharged |
|
Bore |
4 in (11 cm)
|
|
Displacement |
428 cu in (7,014 cu cm)
|
|
Engine Make |
Yanmar |
|
Engine Model |
4TNV94CHT |
|
Engine Model |
Cat C7.1 ACERT |
|
Gross Power |
86 hp (64 kw)
|
|
Gross Power - Sae J1995 |
241 hp (180 kw)
|
|
Net Flywheel Power |
228 hp (170 kw)
|
|
Net Power |
83 hp (62 kw)
|
|
Net Power - Sae J1349/Iso 9249 |
228 hp (170 kw)
|
|
Number Of Cylinders |
4 |
|
Peak Torque |
266 lbs ft (360 nm)
|
|
Power Measured @ |
2,500 rpm |
|
Stroke |
5 in (14 cm)
|
|
Torque Measured @ |
1,700 rpm |
| Hydraulic |
|
Hydraulic Horsepower-Standard Flow |
42 hp (31 kw)
|
|
Pump Flow |
21 gpm (80 lpm)
|
|
Relief Valve Pressure |
3,450 psi |
| Hydraulic System |
|
Boom Cylinder - Bore |
6 in (15 cm)
|
|
Boom Cylinder - Stroke |
55 in (140 cm)
|
|
Db Bucket Cylinder - Bore |
5 in (13 cm)
|
|
Db Bucket Cylinder - Stroke |
46 in (117 cm)
|
|
Main System - Maximum Flow - Total |
130 gpm (492 lpm)
|
|
Maximum Pressure - Equipment - Heavy Lift |
5,511 psi |
|
Maximum Pressure - Equipment - Normal |
5,076 psi |
|
Maximum Pressure - Swing |
3,989 psi |
|
Maximum Pressure - Travel |
5,076 psi |
|
Pilot System - Maximum Flow |
6 gpm (23 lpm)
|
|
Pilot System - Maximum Pressure |
569 psi |
|
Stick Cylinder - Bore |
6 in (15 cm)
|
|
Stick Cylinder - Stroke |
65 in (165 cm)
|
|
Tb Bucket Cylinder - Bore |
6 lb/in |
|
Tb Bucket Cylinder - Stroke |
45 lb/in |
| Loader |
|
Boom Breakout Force |
4,600 lbs (2,087 kg)
|
|
Breakout Force |
10,335 lbs (4,688 kg)
|
|
Operating Load |
2,904 lbs (1,317 kg)
|
|
Tipping Load |
8,307 lbs (3,768 kg)
|
| Operational |
|
Alternator Supplied Amperage |
70 amps |
|
Fuel Capacity |
26 gal (97 l)
|
|
Max Speed - High Range |
8 mph (13 kph)
|
|
Max Speed - Low Range |
5 mph (9 kph)
|
|
Operating Voltage |
12 V |
|
Operating Weight |
11,510 lbs (5,221 kg)
|
| Service Refill Capacities |
|
Cooling System |
12 gal (44 l)
|
|
Engine Oil - With Filter |
6 gal (23 l)
|
|
Final Drive - Each |
2 gal (6 l)
|
|
Fuel Tank Capacity |
137 gal (520 l)
|
|
Hydraulic System - Including Tank |
82 gal (310 l)
|
|
Hydraulic Tank |
41 gal (155 l)
|
|
Swing Drive - Each |
3 gal (10 l)
|
| Sound Performance |
|
Iso 6395 - Spectator Noise |
105 dB(A) |
|
Iso 6396 - Operator Noise (Closed) |
72 dB(A) |
|
Iso 6396 - Operator Noise (Open) |
77 dB(A) |
| Standards |
|
Brakes |
ISO 10265 2008 |
|
Cab/Fogs |
ISO 10262 1998 |
| Swing Mechanism |
|
Swing Speed |
10 rpm |
|
Swing Torque |
60,628 lbs ft (82,199 nm)
|
| Track |
|
Number Of Carrier Rollers - Each Side - Long Undercarriage |
2 |
|
Number Of Shoes - Each Side - Long Undercarriage |
50 |
|
Number Of Track Rollers - Each Side - Long Undercarriage |
9 |
| Undercarriage |
|
Ground Pressure |
5 psi |
|
Number Of Track Rollers Per Side |
5 |
| Weights |
|
Maximum Operating Weight |
68,958 lbs (31,279 kg)
|
|
Maximum Operating Weight** |
68,958 lbs (31,279 kg)
|
|
Minimum Operating Weight |
64,060 lbs (29,057 kg)
|
|
Minimum Operating Weight* |
64,060 lbs (29,057 kg)
|
|
Operating Weight |
68,958 lbs (31,279 kg)
|
