| Blade Range |
|
Blade Tip Range Backward |
5 |
|
Blade Tip Range Forward |
40 |
|
Circle Center Shift Left |
26 in (66 cm)
|
|
Circle Center Shift Right |
26 in (66 cm)
|
|
Maximum Depth Of Cut |
31 in (77 cm)
|
|
Maximum Lift Above Ground |
16 in (41 cm)
|
|
Maximum Shoulder Reach Left |
69 in (176 cm)
|
|
Maximum Shoulder Reach Right |
76 in (193 cm)
|
|
Moldboard Side Shift Left |
20 in (51 cm)
|
|
Moldboard Side Shift Right |
26 in (66 cm)
|
| Boom/Stick 1 |
|
Boom/Stick 1 |
Arm Length 8ft.3in. ( 2.52m |
|
Max Cutting Height |
28 ft (8 m)
|
|
Max Digging Depth |
18 ft (5 m)
|
|
Max Loading Height |
21 ft (6 m)
|
|
Max Reach Along Ground |
26 ft (8 m)
|
|
Max Vertical Wall Digging Depth |
16 ft (5 m)
|
|
Shipping Height Of Unit |
9 ft (3 m)
|
|
Shipping Length Of Unit |
25 ft (8 m)
|
| Boom/Stick 2 |
|
Boom/Stick 2 |
Arm Length 9ft. 11in. (3.01m ) |
|
Max Cutting Height |
29 ft (9 m)
|
|
Max Digging Depth |
20 ft (6 m)
|
|
Max Loading Height |
22 ft (7 m)
|
|
Max Reach Along Ground |
27 ft (8 m)
|
|
Max Vertical Wall Digging Depth |
18 ft (5 m)
|
|
Shipping Height Of Unit |
9 ft (3 m)
|
|
Shipping Length Of Unit |
25 ft (8 m)
|
| Buckets |
|
Reference Bucket Capacity |
1 cu yd |
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
9 ft (3 m)
|
|
Height To Top Of Cab |
9 ft (3 m)
|
|
Length |
26 ft (8 m)
|
|
Length Of Machine* |
387 in (983 cm)
|
|
Length Of Track On Ground |
9 ft (3 m)
|
|
Maximum Height |
151 in (384 cm)
|
|
Note |
*Typically equipped with push block and ripper. |
|
Removal Counterweight Clearance |
3 ft (1 m)
|
|
Tail Swing Radius |
7 ft (2 m)
|
|
Weight |
30,500 lbs (13,835 kg)
|
|
Width |
102 in (259 cm)
|
|
Width |
9 ft (3 m)
|
|
Width All Wheel Drive (Awd) |
2,551 mm (100 in)
|
|
Width To Outside Of Tracks |
9 ft (3 m)
|
| Engine |
|
All-Wheel Drive Net Power Range (Tier 3) |
130 hp (97 kw)
|
|
All-Wheel Drive Net Power Range (Tier 4) |
NaN kW |
|
Aspiration |
Turbocharged |
|
Bore |
4 in (10 cm)
|
|
Derating Altitude |
9,843 ft (3,000 m)
|
|
Derating Altitude (Awd) |
5,499 ft (1,676 m)
|
|
Displacement |
428 cu in (7,010 cu cm)
|
|
Emissions |
U.S. EPA Tier 4 Final/EU Stage IV - U.S. EPA Tier 3/EU Stage IIIA |
|
Engine Make |
2,240 |
|
Engine Model |
4045T |
|
Engine Model |
Cat 7.1 |
|
Max Torque |
260 lbs ft (353 nm)
|
|
Maximum Torque - Awd On |
611 lbs ft (828 nm)
|
|
Maximum Torque - Iso 9249 |
606 lbs ft (822 nm)
|
|
Net Power |
90 hp (67 kw)
|
|
Note (1) |
Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 Standards in effect at the time of manufacture. |
|
Note (2) |
Net power advertised is the power available at rated speed of 2,000 rpm, measured at the flywheel when engine is equipped with fan, air cleaner, muffler and alternator. |
|
Note (3) |
Power as declared per ISO 14396 |
|
Number Of Cylinders |
6 |
|
Power Measured @ |
2,200 rpm |
|
Standard Capability |
122 degrees |
|
Stroke |
5 in (13 cm)
|
|
Torque Measured @ |
1,400 rpm |
|
Torque Rise - Iso 9294 |
42% |
| Machine Weight |
|
Joystick All-Wheel Drive (Awd) Weight* Tier 3 |
36 lbs (17 kg)
|
|
Joystick All-Wheel Drive (Awd) Weight* Tier 4 |
37 lbs (17 kg)
|
|
Joystick Weight* Tier 3 |
35 lbs (16 kg)
|
|
Joystick Weight* Tier 4 |
35 lbs (16 kg)
|
|
Lever/Steering Wheel All-Wheel Drive (Awd) Weight* Tier 3 |
36 lbs (16 kg)
|
|
Lever/Steering Wheel All-Wheel Drive (Awd) Weight* Tier 4 |
37 lbs (17 kg)
|
|
Lever/Steering Wheel Weight* Tier 3 |
35 lbs (16 kg)
|
|
Lever/Steering Wheel Weight* Tier 4 |
35 lbs (16 kg)
|
|
Note (1) |
*Typically equipped includes 4267 mm (14 ft) plus blade, tires, push plate, ripper, bottom guard, operator, and full fluids. |
| Moldboard |
|
Arc Radius |
16 in (41 cm)
|
|
Blade Height |
24 in (61 cm)
|
|
Blade Width |
12 ft (4 m)
|
|
Cutting Edge |
6 in (15 cm)
|
|
End Bit |
6 in (15 cm)
|
|
Throat Clearance |
4 in (10 cm)
|
| Operational |
|
Alternator Supplied Amperage |
45 amps |
|
Cooling System Fluid Capacity |
6 gal (22 l)
|
|
Engine Oil Capacity |
4 gal (13 l)
|
|
Fuel Capacity |
66 gal (250 l)
|
|
Hydraulic Pump Flow Capacity |
27 gpm (101 lpm)
|
|
Hydraulic System Fluid Capacity |
35 gal (132 l)
|
|
Hydraulic System Relief Valve Pressure |
4,980 psi |
|
Operating Voltage |
24 V |
|
Operating Weight |
26,790 lbs (12,150 kg)
|
|
Swing Drive Fluid Capacity |
1 gal (3 l)
|
| Service Refill Capacities |
|
Circle Drive |
2 gal (7 l)
|
|
Cooling System |
14 gal (53 l)
|
|
Diesel Exhaust Fluid Tank (Tier 4 Only) |
5 gal (19 l)
|
|
Engine Crankcase |
5 gal (18 l)
|
|
Fuel Tank |
65 gal (246 l)
|
|
Hydraulic System |
26 gal (97 l)
|
|
Transmission And Differential |
9 gal (34 l)
|
| Swing Mechanism |
|
Swing Speed |
13 rpm |
|
Swing Torque |
22,415 lbs ft (30,390 nm)
|
| Undercarriage |
|
Drawbar Pull |
22,050 lbs (10,000 kg)
|
|
Ground Pressure |
5 psi |
|
Max Travel Speed |
3 mph (5 kph)
|
|
Number Of Carrier Rollers Per Side |
1 |
|
Number Of Shoes Per Side |
44 |
|
Number Of Track Rollers Per Side |
7 |
|
Shoe Size |
24 in (60 cm)
|
|
Track Gauge |
7 ft (2 m)
|
