| Cooling |
|
Cooling system type (Since 2026)
|
Electronically controlled, variable-rate, suction-type cooling fan |
| Cylinders |
|
Arm cylinder bore (in.) (Since 2026)
|
4.53 in. |
|
Arm cylinder rod diameter (in.) (Since 2026)
|
3.15 in. |
|
Arm cylinder stroke (in.) (Since 2026)
|
44.7 in. |
|
Boom cylinder bore (in.) (Since 2026)
|
4.13 in. |
|
Boom cylinder rod diameter (in.) (Since 2026)
|
2.76 in. |
|
Boom cylinder stroke (in.) (Since 2026)
|
37.05 in. |
|
Bucket cylinder bore (in.) (Since 2026)
|
3.94 in. |
|
Bucket cylinder rod diameter (in.) (Since 2026)
|
2.76 in. |
|
Bucket cylinder stroke (in.) (Since 2026)
|
34.45 in. |
|
Number of arm cylinders (Since 2026)
|
1 |
|
Number of boom cylinders (Since 2026)
|
2 |
|
Number of bucket cylinders (Since 2026)
|
1 |
| Electrical |
|
Alternator rating (amp) (Since 2026)
|
100.0 amp |
|
Battery capacity (CCA) (Since 2026)
|
950.0 CCA |
|
Battery voltage (V) (Since 2026)
|
12.0 V |
|
Number of batteries (Since 2026)
|
2 |
|
Work lights (Since 2026)
|
2 LED (1 on left side of boom, 1 on frame) |
| Engine |
|
Aspiration type (Since 2026)
|
Turbocharged, air-to-air charge-air cooler |
|
Cylinders (Since 2026)
|
4 |
|
Displacement (cu in.) (Since 2026)
|
275.0 cu in. |
|
Manufacturer (Since 2026)
|
John Deere |
|
Net power (rpm) (Since 2026)
|
2000.0 rpm |
|
Net power at net power rpm (ISO 9249) (hp) (Since 2026)
|
98.0 hp |
|
Non-road emission standards (Since 2026)
|
EPA Final Tier 4/EU Stage IV |
|
Off-level capacity (%) (Since 2026)
|
70.0 % |
|
Off-level capacity (degrees) (Since 2026)
|
35.0 degrees |
| General Specifications |
|
Digging Depth (Since 2025)
|
18.2–19.8 |
|
Digging Reach (Since 2025)
|
29 ft (9 m)
|
|
Engine (Since 2025)
|
98 hp (73 kw)
|
|
Operating Weight (Since 2025)
|
29,531 to 30,573 |
| Ground Pressure |
|
24-in. rubber crawler pad with blade (psi) (Since 2026)
|
5.37 psi |
|
24-in. rubber crawler pad without blade (psi) (Since 2026)
|
4.06 psi |
|
24-in. triple semi-grouser shoes with blade (psi) (Since 2026)
|
5.11 psi |
|
24-in. triple semi-grouser shoes without blade (psi) (Since 2026)
|
5.51 psi |
|
28-in. triple semi-grouser shoes with blade (psi) (Since 2026)
|
5.21 psi |
|
28-in. triple semi-grouser shoes without blade (psi) (Since 2026)
|
4.64 psi |
| Hydraulics |
|
Controls type (Since 2026)
|
Pilot levers, short stroke, low-effort hydraulic pilot controls with shutoff lever |
|
Hydraulics type (Since 2026)
|
Open center, load sensing |
|
Implement circuits system operating pressure (psi) (Since 2026)
|
4980.0 psi |
|
Main pump maximum rated flow per pump (gpm) (Since 2026)
|
28.0 gpm |
|
Main pump type (Since 2026)
|
2 variable-displacement axial-piston pumps |
|
Number of pumps (Since 2026)
|
2 |
|
Pilot pump maximum rated flow (gpm) (Since 2026)
|
8.7 gpm |
|
Pilot pump number of gears (Since 2026)
|
1 |
|
Pilot pump pressure setting (psi) (Since 2026)
|
570.0 psi |
|
Power boost system operating pressure (psi) (Since 2026)
|
5265.0 psi |
|
Pump 2 maximum rated flow per pump (gpm) (Since 2026)
|
28.0 gpm |
|
Swing circuits system operating pressure (psi) (Since 2026)
|
4685.0 psi |
|
Travel circuits system operating pressure (psi) (Since 2026)
|
4980.0 psi |
| Operating weights of excavator with blade |
|
Conditions for measuring operating weights with blade (Since 2026)
|
With full fuel tank; 79-kg (175 lb.) operator; 914-mm (36 in.), 0.50-m³ (0.65 cu. yd.), 414-kg (913 lb.) general-purpose bucket; 3.01-m (9 ft. 11 in.) arm; and 2350-kg (5,181 lb.) counterweight |
|
With 24-in. rubber crawler pad (lb) (Since 2026)
|
31502.0 lb. |
|
With 24-in. triple semi-grouser shoes (lb) (Since 2026)
|
30009.0 lb. |
|
With 28-in. triple semi-grouser shoes (lb) (Since 2026)
|
30573.0 lb. |
| Operating weights of excavator without blade |
|
Conditions for measuring operating weights without blade (Since 2026)
|
With full fuel tank; 79-kg (175 lb.) operator; 914-mm (36 in.), 0.50-m³ (0.65 cu. yd.), 414-kg (913 lb.) general-purpose bucket; 3.01-m (9 ft. 11 in.) arm; and 2350-kg (5,181 lb.) counterweight |
|
With 24-in. rubber crawler pad (lb) (Since 2026)
|
30500.0 lb. |
|
With 24-in. triple semi-grouser shoes (lb) (Since 2026)
|
29007.0 lb. |
|
With 28-in. triple semi-grouser shoes (lb) (Since 2026)
|
29531.0 lb. |
| Operating weights of optional components with blade |
|
1-piece boom, with arm cylinder (lb) (Since 2026)
|
2176.0 lb. |
|
24-in. rubber crawler pad (lb) (Since 2026)
|
12456.0 lb. |
|
24-in. triple semi-grouser shoes (lb) (Since 2026)
|
10961.0 lb. |
|
28-in. triple semi-grouser shoes (lb) (Since 2026)
|
11525.0 lb. |
|
8-ft, 3-in. arm with bucket and linkage (lb) (Since 2026)
|
949.0 lb. |
|
9-ft, 11-in. arm with bucket and linkage (lb) (Since 2026)
|
1104.0 lb. |
|
Boom-lift cylinders (2), total weight (lb) (Since 2026)
|
960.0 lb. |
| Operating weights of optional components without blade |
|
1-piece boom, with arm cylinder (lb) (Since 2026)
|
2176.0 lb. |
|
24-in. rubber crawler pad (lb) (Since 2026)
|
11453.0 lb. |
|
24-in. triple semi-grouser shoes (lb) (Since 2026)
|
9958.0 in. |
|
28-in. triple semi-grouser shoes (lb) (Since 2026)
|
10482.0 lb. |
|
8-ft, 3-in. arm with bucket and linkage (lb) (Since 2026)
|
949.0 lb. |
|
9-ft, 11-in. arm with bucket and linkage (lb) (Since 2026)
|
1104.0 lb. |
|
Boom-lift cylinders (2), total weight (lb) (Since 2026)
|
960.0 lb. |
| Powertrain |
|
Drawbar pull (lb) (Since 2026)
|
24729.0 lb. |
|
Maximum travel speed high/fast (mph) (Since 2026)
|
3.4 mph |
|
Maximum travel speed low/slow (mph) (Since 2026)
|
2.1 mph |
|
Powertrain type (Since 2026)
|
2-speed propel with automatic shift |
| Refill Capacities |
|
Cooling system (qt) (Since 2026)
|
24.8 qt |
|
Diesel-exhaust fluid (DEF) (qt) (Since 2026)
|
28.2 qt |
|
Engine oil with filter (qt) (Since 2026)
|
18.0 qt |
|
Fuel tank (gal.) (Since 2026)
|
75.3 gal. |
|
Hydraulic system (gal.) (Since 2026)
|
48.9 gal. |
|
Hydraulic tank (gal.) (Since 2026)
|
18.2 gal. |
|
Propel gearbox (qt) (Since 2026)
|
4.2 qt |
|
Swing gearbox (qt) (Since 2026)
|
3.4 qt |
| Swing Mechanism |
|
Speed (rpm) (Since 2026)
|
13.3 rpm |
|
Torque (lb-ft) (Since 2026)
|
25000.0 lb-ft |
| Undercarriage |
|
Number of carrier rollers per side (Since 2026)
|
1 |
|
Number of shoes per side (Since 2026)
|
44 |
|
Number of track rollers per side (Since 2026)
|
7 |
|
Track adjustment type (Since 2026)
|
Hydraulic |
|
Track chain type (Since 2026)
|
Sealed and lubricated |
|
Track guides (Since 2026)
|
None |
