| Air Conditioning System |
|
Air Conditioning |
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.1 kg of refrigerant which has a CO2 equivalent of 1.573 metric tonnes. |
| Buckets |
|
Capacity - General Purpose |
2 cu yd |
|
Capacity - Multi-Purpose |
2 cu yd |
|
Capacity - Performance Series |
3 cu yd |
|
Note |
Buckets equipped with teeth and segments. |
|
Width - General Purpose |
98 in (248 cm)
|
|
Width - Multi-Purpose |
97 in (247 cm)
|
|
Width - Performance Series |
100 in (253 cm)
|
| Dimensions |
|
Bucket Height - Carry Position |
22 in (55 cm)
|
|
Carry Position Approach Angle |
15 degrees |
|
Clearance At Full Lift Height And 45 Degrees Dump* |
106 in (269 cm)
|
|
Digging Depth* |
6 in (14 cm)
|
|
Grading Angle |
74 degrees |
|
Height - Bucket Hinge Pin |
142 in (361 cm)
|
|
Height - Top Of Stack |
110 in (280 cm)
|
|
Machine Height - Top Of Cab |
124 in (315 cm)
|
|
Maximum Rollback - Ground/Carry Position |
43 degrees/50 degrees |
|
Maximum Rollback/Dump - Fully Raised |
52 degrees/53 degrees |
|
Note |
*With general purpose bucket and extra duty teeth. |
|
Overall Machine Height - Bucket Fully Raised |
184 in (467 cm)
|
|
Overall Machine Length* |
252 in (639 cm)
|
|
Overall Machine Width Without Bucket: Narrow Tracks - 380 Mm (14.9 In) Shoes |
87 in (221 cm)
|
|
Overall Machine Width Without Bucket: Standard Tracks - 480 Mm (19.7 In) Shoes |
91 in (232 cm)
|
|
Ramp Angle |
29 degrees |
|
Reach At Full Lift Height And 45 Degrees Dump* |
47 in (119 cm)
|
|
Tail Swing Radius |
11 ft (3 m)
|
| Engine |
|
Displacement |
549 cu in (8,997 cu cm)
|
|
Emissions |
U.S. EPA Tier 4 Final/EU Stage IV/Korea Tier 4 Final or China Nonroad Stage III, India Bharat III, Eurasian Economic Union Stage IIIA, UN ECE R96 Stage IIIA emission standards, equivalent to Tier 3/Stage IIIA |
|
Engine Make |
2,240 |
|
Engine Model |
PowerTech Plus 6090H |
|
Engine Model |
Cat C7.1 ACERT |
|
Flywheel Power |
154 hp (115 kw)
|
|
Gross Power |
330 hp (246 kw)
|
|
Net Power |
286 hp (213 kw)
|
|
Net Power (Rated) - Sae J1349/Iso 9249 |
154 hp (115 kw)
|
|
Net Power - Rated - Iso 9249 (Din) |
156 hp (116 kw)
|
|
Net Torque |
1,027 lbs ft (1,392 nm)
|
|
Note (1) |
All nonroad Tier 4 Interim and Final, Stage IIIB and IV and Korea Tier 4 Final diesel engines are required to use only Ultra Low Sulfur Diesel (ULSD) with 15 ppm (mg/kg) of sulfur or less, or up to B20 biodiesel blended with ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214). Cat DEO-ULS or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. Consult your OMM for further machine specific fuel re |
|
Note (2) |
Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241. |
|
Number Of Cylinders |
6 |
| General |
|
Note |
For complete machine specifications and available configurations, please see your Cat dealer or look on this website. |
| Operational |
|
Fuel Capacity |
295 gal (1,117 l)
|
|
Hydraulic System Fluid Capacity |
82 gal (310 l)
|
|
Max Speed |
1 mph (2 kph)
|
|
Operating Voltage |
24 V |
|
Operating Weight |
33,852 lbs (15,352 kg)
|
|
Swing Speed |
6 rpm |
| Service Refill Capacities |
|
Def Tank(1) |
4 gal (16 l)
|
|
Fuel Tank |
70 gal (265 l)
|
|
Note |
(1) Machine equipped with Tier 4 Final/Stage IV emissions reduction technology. |
| Undercarriage |
|
Ground Contact Area - Optional Shoe |
2790 in2 |
|
Ground Contact Area - Standard Shoe |
3410 in2 |
|
Ground Pressure - Optional Shoe |
11 psi |
|
Ground Pressure - Standard Shoe |
9 psi |
|
Ground Pressure(1) - Optional Shoe |
11 psi |
|
Ground Pressure(1) - Standard Shoe |
9 psi |
|
Grouser Height - Double Grouser |
1 in (4 cm)
|
|
Note |
(1) Machine equipped with Tier 4 Final/Stage IV emissions reduction technology. |
|
Track Gauge |
6 ft (2 m)
|
|
Track On Ground |
91 in (232 cm)
|
|
Track Rollers/Shoes - Each Side |
Jun-37 |
|
Track Shoe Width - Optional |
15 in (38 cm)
|
|
Track Shoe Width - Standard |
19 in (48 cm)
|
| Weights |
|
Note |
(1) Machine equipped with Tier 4 Final/Stage IV emissions reduction technology. |
|
Operating Weight(1) |
34,484 lbs (15,639 kg)
|
