2019 John Deere 9520R For Sale in Watrous, SK

2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R
2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R 2019 John Deere 9520R

/ Save to Watch List

Email Dealer


For Sale: $397,177.00 USD
Converted From: 565,000.00 CAD

Apply for Financing


Machine Info:

Serial Number:1RW9520RVKP062554
Stock Number:2AU62554
Machine Location:WATROUS, SK

Description:

Power Shift, Duals, Hydraulic Pump: Big, PTO: Yes, Guidance-ready: Yes, Guidance Receiver: Yes, Guidance Display: Yes, HydraCushion Axle, Performance Packagee, 18 Transmission, 18 F/6 R Speeds with Efficiency Manager, 4600 Command Center, John Deere Active Command Steering (ACS)StarFire 6000 Receiver - SF1 Command Center Premium Activation 3.04600 Processor, Premium Command View III Cab with Active Seat, Premium Radio Package, John Deere PowerTech PSS 13.5 L (824 cu. in.) 6 Cylinder Tier 4/Stage V Compliant Diesel Engine, 435 L/min (115 gpm) Dual Hydraulic Pump, Five Rear Remote SCVs with Electrohydraulic (EH) Controls (Dual Hydraulic Pump Hydraulic System)45 mm (1-3/4 in.) 1,000 rpm (20-Spline) PTO, Cat. 5 Drawbar (2 position) with Heavy-Duty Drawbar Support with 70 mm (2.75 in.) Pin120 mm (4.72 in.) diameter by 3,048 mm (120 in.) length Double Reduction w/ HydraCushion Suspension System, IF800/70R38 179A8 R1W Increased Flexion Radial in Dual Wheel Configuration, Michelin Brand Only, Premium Lighting, Tow Cable, Ethernet Switch, Leather Comfort Package, Outside Mirrors- Power Telescoping, Electrically Adjustable Right-Hand Arm, Radar, Dual Beam Sensor, Antenna Mount and Wiring for Business Band (2-Way) Radio, Actively Cooled Refrigeration Unit 6.4 L³ (391 cu. in.)Auxiliary Hydraulic Connections - 1/2 in.Second Rotary Beacon Light, High Capacity 240 amp Alternator, Hydraulic Trailer Brake Valve, Greaseable Steering Cylinder Pins, Front Weight Support without Front Weights 3,874 kg (8,542 lb)

Machine Details:

General Specifications
TransmissionPower Shift
TiresDuals
Hydraulic PumpBig
PTOYes
Rear 3-Point HitchNo
Guidance-readyYes
Guidance ReceiverYes
Guidance DisplayYes
OptionsHydraCushion Axle


From the manufacturer:

Supplied by HeavyEquipmentData.com →

Capacities - 4WD
Cooling System 15 gal (56 l)
Crankcase Oil Volume 13 gal (48 l)
Diesel Exhaust Fluid (Def) Tank 22 gal (83 l)
Fuel Tank - Diesel 400 gal (1,514 l)
Transmission-Hydraulic System 60 gal (227 l)
Dimensions
Height 12 ft (4 m)
Length 24 ft (7 m)
Weight 41,950 lbs (19,028 kg)
Width 15 ft (4 m)
Dimensions - 4WD
Approx. Shipping Weight 43,550 lbs (19,754 kg)
Drawbar Clearance 17 in (42 cm)
Overall Length 303 in (770 cm)
Wheelbase 154 in (391 cm)
Electrical - 4WD
Alternator Size 200 amp
Battery Options 12 V
Engine - 4WD
After Treatment Type DOC/DPF/SCR
Aspiration Dual series turbocharger with fixed geometry first stage, variable geometry second stage; air-to-air aftercooling and cooled exhaust gas recirculation
Description John Deere PowerTechTM PSS 13.5L (B20 diesel compatible)
Displacement 824 cu in (13,501 cu cm)
Emission Level Final Tier 4
Engine Type Diesel, in-line, 6-cylinder, wet-sleeve cylinder liners with 4 valves-in-head
Family JJDXL13.5310
Peak Torque 380 lbs ft (515 nm)
Power Boost (Available In Transport And/Or Mobile Pto Applications) 10 percent
Rated Engine Speed 2,100 rpm
Rated Power 520 hp (388 kw)
Rated Pto Power 335 hp (250 kw)
Torque Rise 38 %
Front Axle - 4WD
Front Axle Differential Lock Full-locking electrohydraulic
Hydraulic - 4WD
Available Flow At A Single Rear Scv 35 gpm (132 lpm)
Number Of Rear Selective Controls Valves (Scvs) Standard: ISO Couplers: 4-6 Optional: ISO Couplers: 7-8 (field installed)
Pump Rated Output 115 gpm (435 lpm)
Pump Rated Output 1 58 gpm (220 lpm)
Scv Control Electronic
Operator Station - 4WD
Cab Glass Area 6.52 m2 70.18 sq ft
Display Standard: 4100 Generation 4 CommandCenter™ with 7 in. display Optional: 4600 Generation 4 CommandCenter™ with 10 in. display
Inner Cab Volume 3.597 m3 127 cu ft
Instructional Seat Standard
Radio Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna
Seat Standard: ComfortCommand™ Optional: ActiveSeat™
Rear Axle - 4WD
Final Drive Type Inboard planetary with double-reduction axle
Rear Axle Type Standard: Diameter: 120 x 3,048 mm 4.72 x 120 in.
Rear Differential Lock Full-locking electrohydraulic
Rear Hitch - 4WD
Hitch Category (Sae Designation) 15,000 lbs (6,804 kg)
Maximum Lift Capacity Behind Lift Points 20,000 lbs (9,072 kg)
Sensing Type Electrohydraulic with draft sensing
Rear Power Take -Off (Pto) - 4WD
Rear Power Take -Off (Pto) Type 2 in (5 cm)
Steering - 4WD
Steering Type Standard: Hydraulic power-steering Optional: ActiveCommand™ Steering (ACS)
Tires - 4WD
Turning Radius Without Brakes 20 ft (6 m)
Transmission - 4WD
Transmission Type Standard: John Deere e18™ 18-speed PowerShift with Efficiency Manager™: 40 km/h 25 mph
Weights - 4WD
Base Machine Weight 43,550 lbs (19,754 kg)
Maximum Ballast Level 60,000 lbs (27,216 kg)
