| Cooling |
|
Engine Coolant Rating (Since 2026)
|
-34 f |
|
Fan (Since 2026)
|
Hydraulically driven, proportionally controlled |
| Cylinders |
|
Cylinders Type (Since 2026)
|
Heat-treated, chrome-plated, polished cylinder rods; hardened steel (replaceable bushings) pivot pins |
| Electrical And Lighting |
|
Alternator Rating (Since 2026)
|
80 amp |
|
Battery Capacity (Since 2026)
|
925.0 CCA |
|
Lights (SAE 99) (Since 2026)
|
Driving/front working lights (2), turn signals, flashers, and stop- and taillights |
|
Number Of Batteries (Since 2026)
|
1 |
|
System Type (Since 2026)
|
Electrical load center with blade-type multi-fused circuits |
|
Voltage (Since 2026)
|
12 v |
| Engine |
|
Air Cleaner (Since 2026)
|
Dual safety element dry type |
|
Aspiration (Since 2026)
|
Turbocharged |
|
Cylinders (Since 2026)
|
4 |
|
Displacement (Since 2026)
|
203 cu in (3,327 cu cm)
|
|
Engine Bore And Stroke (Since 2026)
|
3.89 x 4.33 in. |
|
Engine Manufacturer (Since 2026)
|
Yanmar |
|
Engine Model (Since 2026)
|
4TNV98CT |
|
Lubrication (Since 2026)
|
Pressure system with full-flow spin-on filter |
|
Non-Road Emission Standards (Since 2026)
|
EPA Final Tier 4/EU Stage V |
|
Valves Per Cylinder (Since 2026)
|
4 |
| General Specifications |
|
Bucket Capacity (Since 2023)
|
1.0 - 2.1 (0.8 - 1.6) |
|
Bucket Capacity (2024)
|
1.0 - 2.1 (0.8 - 1.6) |
|
Bucket Capacity (Since 2025)
|
1.0 - 2.1 |
|
Bucket Capacity (2026)
|
1.0 - 2.1 |
|
Engine Power (Since 2023)
|
71 hp (53 kw)
|
|
Engine Power (2024)
|
71 hp (53 kw)
|
|
Engine Power Net (Since 2025)
|
71 hp (53 kw)
|
|
Engine Power Net (2026)
|
71 hp (53 kw)
|
|
Engine type (Since 2023)
|
Yanmar 4TNV98CT |
|
Engine type (2024)
|
Yanmar 4TNV98CT |
|
Engine type (2025)
|
Yanmar 4TNV98CT |
|
Engine type (2026)
|
Yanmar 4TNV98CT |
|
Max Dump Height (Since 2023)
|
9 ft (3 m)
|
|
Max Dump Height (2024)
|
9 ft (3 m)
|
|
Max Dump Height (2025)
|
9 ft (3 m)
|
|
Max Dump Height (2026)
|
9 ft (3 m)
|
|
Operating Weight (Since 2023)
|
14,110 lbs (6,400 kg)
|
|
Operating Weight (Since 2024)
|
14,110–14,253 (6400–6465) |
|
Operating Weight (Since 2025)
|
14,110–14,253 |
|
OperatingWeight (Since 2026)
|
14,110–14,253 |
| Hydraulics |
|
Controls Type (Since 2026)
|
Pilot-operated, 3-function valve with single-lever control for boom and bucket, standard pin disconnect and third-function proportional electrohydraulic (EH) auxiliary hydraulics |
|
Hydraulic Dump Cycle Time (Since 2026)
|
2 s |
|
Hydraulic Lower (Power Down) Cycle Time (Since 2026)
|
4 s |
|
Hydraulic Raise Cycle Time (Since 2026)
|
6 s |
|
Main Pump (Loader and Steering) (Since 2026)
|
Fixed-displacement gear pump; open-center system |
|
Maximum Pressure at Couplings (Since 2026)
|
3,045 psi |
|
System Relief Pressure (Loader) (Since 2026)
|
2,750 psi |
|
System Relief Pressure (Steering) (Since 2026)
|
2,611 psi |
|
Total Cycle Time (Since 2026)
|
12 s |
| Operator Station and Controls |
|
Noise Level for Bystander (ISO 6395) (Since 2026)
|
101 dBA |
|
Noise Level For Operator (ISO 6396) (Since 2026)
|
68 dBA |
| Powertrain |
|
Articulation Arc (Since 2026)
|
60.0 degree (angle) |
|
Degree Of Articulation Left And Right (Since 2026)
|
30.0 degree (angle) |
|
Differentials Front (Since 2026)
|
Locking |
|
Differentials Rear (Since 2026)
|
Open |
|
Final Drive Type (Since 2026)
|
Heavy-duty outboard planetary |
|
Maximum Rise And Fall, Single Wheel (Since 2026)
|
15 in (37 cm)
|
|
Parking Brake (SAE J1473, ISO3450) (Since 2026)
|
Automatically spring-applied, hydraulically released, internal wet disc |
|
Service Brakes (SAE J1473, ISO3450) (Since 2026)
|
Hydraulically actuated, self-adjusting internal wet-disc brake and driveline drum brake |
|
Steering Type (Since 2026)
|
Hydraulic power steering (SAE J1511); 30-degree articulation left and right with mechanical-actuated rear-wheel steering |
|
Steering Wheel Number Of Turns Left Stop To Stop (Since 2026)
|
2 |
|
Steering Wheel Turns Right Stop to Stop (Since 2026)
|
3 |
| Serviceability |
|
Cooling System (Engine and Radiator) Refill Capacity (Since 2026)
|
13 qt |
|
Differential and Planetary Front Axle Refill Capacity (Since 2026)
|
8 qt |
|
Differential and Planetary Rear Axle Refill Capacity (Since 2026)
|
7 qt |
|
Engine Oil with Filter Refill Capacity (Since 2026)
|
11 qt |
|
Fuel Tank Refill Capacity (Since 2026)
|
24 gal (90 l)
|
|
Hydraulic/hydrostatic Reservoir with Filter Refill Capacity (Since 2026)
|
17 gal (66 l)
|
|
Hydrostatic Motor Gearbox Refill Capacity (Since 2026)
|
2 qt |
| Wheels And Tires |
|
Change in Vertical Height 400/70R20 Nokian Hakkapeliitta TRI Tires on Single-Piece Rims (Since 2026)
|
0 in |
|
Change in Vertical Height: 400/70R20 Michelin XMCL Tires on Single-Piece Rims (Since 2026)
|
0 in |
|
Change in Vertical Height: 405/70R18 Firestone Duraforce Tires on Single-Piece Rims (Since 2026)
|
1 in (3 cm)
|
|
Tread Width 400/70R20 Nokian Hakkapeliitta TRI Tires on Single-Piece Rims (Since 2026)
|
64 in (163 cm)
|
|
Tread Width: 400/70R20 Michelin XMCL Tires on Single-Piece Rims (Since 2026)
|
64 in (163 cm)
|
|
Tread Width: 405/70R18 Firestone Duraforce Tires on Single-Piece Rims (Since 2026)
|
64 in (163 cm)
|
|
Tread Width: 405/70R20 Mitas EM-01 Tires on Single-Piece Rims (Since 2026)
|
64 in (163 cm)
|
|
Width Over Tires 400/70R20 Nokian Hakkapeliitta TRI Tires on Single-Piece Rims (Since 2026)
|
82 in (208 cm)
|
|
Width Over Tires: 400/70R20 Michelin XMCL Tires on Single-Piece Rims (Since 2026)
|
82 in (208 cm)
|
|
Width Over Tires: 405/70R18 Firestone Duraforce Tires on Single-Piece Rims (Since 2026)
|
82 in (208 cm)
|
|
Width Over Tires: 405/70R20 Mitas EM-01 Tires on Single-Piece Rims (Since 2026)
|
82 in (208 cm)
|
