| Axles And Brakes |
|
Final Drives (Since 2026)
|
Heavy-duty mid-board planetary |
|
Optional Differentials Front (Since 2026)
|
Dual locking |
|
Optional Differentials Rear (Since 2026)
|
Dual locking |
|
Parking Brake (ISO 3450) (Since 2026)
|
Automatic spring applied, hydraulically released, driveline mounted, sealed wet multi disc |
|
Rear Axle Oscillation, Distance Each Direction (Since 2026)
|
12 degrees |
|
Rear Axle Oscillation, Stop To Stop, With 17.5 R 25 Tires (Since 2026)
|
24 degrees |
|
Service Brakes (ISO 3450) (Since 2026)
|
Outboard, forced oil cooled, multi disc |
|
Standard Differentials Front (Since 2026)
|
Hydraulic locking |
|
Standard Differentials Rear (Since 2026)
|
Conventional |
|
Tire Size Used To Measure Oscillation (Since 2026)
|
17.5 R 25 |
| Cooling |
|
Fan Drive Type (Since 2026)
|
Hydraulically Driven, Proportionally Controlled, Fan Aft of Coolers |
| Electrical And Lighting |
|
Battery Capacity Per Each (Since 2026)
|
950.0 CCA |
|
Battery Voltage (Since 2026)
|
12 v |
|
Number Of Batteries (Since 2026)
|
2 |
|
Optional Alternator Rating (Since 2026)
|
140 amp |
|
Standard Alternator Rating (Since 2026)
|
100 amp |
|
System Type (Since 2026)
|
24 volt with 100-amp alternator (140 amp alternator optional) |
| Engine |
|
Air Cleaner (Since 2026)
|
Under-hood, dual-element dry type, restriction indicator in cab monitor for service |
|
Aspiration (Since 2026)
|
Turbocharged, charge air cooled |
|
Cylinders (Since 2026)
|
4 |
|
Displacement (Since 2026)
|
276 cu in (4,523 cu cm)
|
|
Fuel System (Electronically Controlled) (Since 2026)
|
High-Pressure common rail |
|
Gross Peak Power (Since 2026)
|
1,800 rpm |
|
Gross Peak Power At Rated RPM (ISO 9249) (Since 2026)
|
138 hp (103 kw)
|
|
Gross Peak Torque (Since 2026)
|
1,400 rpm |
|
Gross Peak Torque At Rated RPM (ISO 9249) (Since 2026)
|
405 lbs ft (549 nm)
|
|
Lubrication (Since 2026)
|
Full-flow spin-on filter and integral cooler |
|
Manufacturer (Since 2026)
|
John Deere |
|
Net Peak Power (Since 2026)
|
2,100 rpm |
|
Net Peak Power At Rated RPM (ISO 9249) (Since 2026)
|
124 hp (92 kw)
|
|
Net Peak Torque (Since 2026)
|
1,400 rpm |
|
Net Peak Torque At Rated RPM (ISO 9249) (Since 2026)
|
392 lbs ft (531 nm)
|
|
Net Torque Rise (Since 2026)
|
34.0 % |
|
Non-Road Emission Standards (Since 2026)
|
EPA Final Tier 4/EU Stage V |
|
Valves Per Cylinder (Since 2026)
|
4 |
| General Specifications |
|
Bucket Capacity (Since 2021)
|
2.5–4.5 (1.9–3.4) |
|
Bucket Capacity (2022)
|
2.5–4.5 (1.9–3.4) |
|
Bucket Capacity (2023)
|
2.5–4.5 (1.9–3.4) |
|
Bucket Capacity (2024)
|
2.5–4.5 (1.9–3.4) |
|
Bucket Capacity (Since 2025)
|
2.5–4.5 |
|
Bucket Capacity (2026)
|
2.5–4.5 |
|
Engine Power (Since 2021)
|
124 hp (92 kw)
|
|
Engine Power (2022)
|
124 hp (92 kw)
|
|
Engine Power (2023)
|
124 hp (92 kw)
|
|
Engine Power (2024)
|
124 hp (92 kw)
|
|
Engine Power Net (Since 2025)
|
124 hp (92 kw)
|
|
Engine Power Net (2026)
|
124 hp (92 kw)
|
|
Engine type (Since 2021)
|
Deere PSS 4045 |
|
Engine type (Since 2022)
|
Deere PowerTech PSS 4045 |
|
Engine type (2023)
|
Deere PowerTech PSS 4045 |
|
Engine type (2024)
|
Deere PowerTech PSS 4045 |
|
Engine type (2025)
|
Deere PowerTech PSS 4045 |
|
Engine type (2026)
|
Deere PowerTech PSS 4045 |
|
Max Dump Height (Since 2021)
|
8 ft (3 m)
|
|
Max Dump Height (2022)
|
8 ft (3 m)
|
|
Max Dump Height (2023)
|
8 ft (3 m)
|
|
Max Dump Height (2024)
|
8 ft (3 m)
|
|
Max Dump Height (2025)
|
8 ft (3 m)
|
|
Max Dump Height (2026)
|
8 ft (3 m)
|
|
Operating Weight (Since 2021)
|
25,814–27,670 (11 709–12 551) |
|
Operating Weight (Since 2022)
|
25,814–27,670 (11,709–12,551) |
|
Operating Weight (2023)
|
25,814–27,670 (11,709–12,551) |
|
Operating Weight (Since 2024)
|
25,814–27,368 (11 709–12 414) |
|
Operating Weight (Since 2025)
|
25,814–27,670 |
|
OperatingWeight (Since 2026)
|
25,814–27,670 |
| Hydraulic System And Steering |
|
Hydraulic Dump Cycle Time (Since 2026)
|
1 s |
|
Hydraulic Lower (Power Down) Cycle Time (Since 2026)
|
4 s |
|
Hydraulic Raise Cycle Time (Since 2026)
|
6 s |
|
Hydraulic Total Cycle Time (Since 2026)
|
11 s |
|
Loader Controls (Since 2026)
|
Two-function valve; joystick control or fingertip controls; hydraulic function enable/disable; optional third with roller or auxiliary lever and fourth function valve with dual roller |
|
Max Rated Flow At Rated RPM (Since 2026)
|
36 gpm (136 lpm)
|
|
Pump Type And System (Loader And Steering) (Since 2026)
|
Variable-displacement, axial-piston pump; closed-center, pressure-compensating system |
|
Rated RPM (Since 2026)
|
2,350 rpm |
|
Steering Articulation Angle Each Direction (Since 2026)
|
40 degrees |
|
Steering Articulation Full Arc Angle (Since 2026)
|
80 degrees |
|
Steering Type (ISO 5010) (Since 2026)
|
Power, fully hydraulic |
|
System Pressure At Max Rated Flow (Since 2026)
|
1,000 psi |
|
System Relief Pressure (Loader And Steering) (Since 2026)
|
3,600 psi |
|
Turning Radius (Measured To Centerline Of Outside Tire) (Since 2026)
|
15.58 ft, in. |
| Key Specs |
|
Net Peak Power (Since 2026)
|
2,100 rpm |
|
Net Peak Power At Rated RPM (ISO 9249) (Since 2026)
|
124 hp (92 kw)
|
|
Net Peak Torque (Since 2026)
|
1,400 rpm |
|
Net Peak Torque At Rated RPM (ISO 9249) (Since 2026)
|
392 lbs ft (531 nm)
|
| Maximum Forward Travel Speeds (Standard 5-Speed With Lockup Torque Converter) |
|
Range 1 (Since 2026)
|
5 mph (7 kph)
|
|
Range 2 (Since 2026)
|
8 mph (12 kph)
|
|
Range 3 (Since 2026)
|
15 mph (23 kph)
|
|
Range 4 (Since 2026)
|
22 mph (35 kph)
|
|
Tire Size Used To Measure Travel Speeds (Since 2026)
|
17.5R25 |
| Serviceability |
|
Axle Oil Without Coolers (Front And Rear, Each) Refill Capacity (Since 2026)
|
23 gal (87 l)
|
|
Cooling System Refill Capacity (Since 2026)
|
25 qt |
|
Diesel-Exhaust Fluid (DEF) Refill Capacity (Since 2026)
|
17 qt |
|
Engine Oil With Vertical Spin-On Filter Refill Capacity (Since 2026)
|
15 qt |
|
Fuel Tank (With Lockable Cap) Refill Capacity (Since 2026)
|
60 gal (227 l)
|
|
Hydraulic Reservoir With Filter Refill Capacity (Since 2026)
|
22 gal (82 l)
|
|
Parking Brake Oil (Wet Disc) Refill Capacity (Since 2026)
|
12.0 oz. |
|
Transmission Reservoir With Vertical Filter Refill Capacity (Since 2026)
|
20 gal (74 l)
|
| Transmission System |
|
Operator Interface (Since 2026)
|
Steering-column or joystick-mounted F-N-R and gear-select lever; kick-down button on hydraulic lever |
|
Shift Control (Since 2026)
|
Electronically modulated, adaptive, load and speed dependent |
|
Shift Modes (Since 2026)
|
Manual/auto (1st-D or 2nd-D); Quick shift button with 2 selectable modes: kick-down or kick-up/down; and 4 clutch cutoff setting |
|
Torque Converter (Since 2026)
|
Single-stage, single-phase |
|
Type (Since 2026)
|
Countershaft-type PowerShift™ |
| Wheels And Tires |
|
Tire Size Used To Measure (Since 2026)
|
Michelin 17.5 R 25, 1 Star L-3 |
|
Tread Width On Standard Tires (Since 2026)
|
75 in (190 cm)
|
|
Width Over Tires On Standard Tires (Since 2026)
|
95 in (242 cm)
|
