| Axles And Brakes |
|
Final Drives (Since 2026)
|
Heavy-duty inboard-mounted planetary |
|
Parking Brake (ISO 3450) (Since 2026)
|
Automatic spring applied, hydraulically released, driveline mounted, sealed wet multi disc |
|
Rear Axle Oscillation, Distance Each Direction (Since 2026)
|
12 degrees |
|
Rear Axle Oscillation, Stop To Stop (Since 2026)
|
24 degrees |
|
Service Brakes (ISO 3450) (Since 2026)
|
Hydraulically actuated, spring retracted, self-adjusting, inboard sun-shaft mounted, oil cooled, single disc |
|
Tire Size Used To Measure Oscillation (Since 2026)
|
20.5 R 25 |
| Cooling |
|
Fan Drive Type (Since 2026)
|
Hydraulically driven, proportionally controlled, fan forward of coolers |
| Electrical And Lighting |
|
Battery Capacity Per Each (Since 2026)
|
950.0 CCA |
|
Battery Voltage (Since 2026)
|
12 v |
|
System Type (Since 2026)
|
24 volt with 100-amp alternator |
| Engine |
|
Air Cleaner (Since 2026)
|
Under-hood, dual-element dry type, restriction indicator in cab monitor for service |
|
Aspiration (Since 2026)
|
Turbocharged, charge air cooled |
|
Cylinders (Since 2026)
|
4 |
|
Displacement (Since 2026)
|
276 cu in (4,523 cu cm)
|
|
Fuel System (Electronically Controlled) (Since 2026)
|
High-pressure common rail |
|
Lubrication (Since 2026)
|
Full-flow spin-on filter and integral cooler |
|
Manufacturer (Since 2026)
|
John Deere |
|
Net Peak Power (Since 2026)
|
1,800 rpm |
|
Net Peak Power At Rated RPM (ISO 9249) (Since 2026)
|
168 hp (125 kw)
|
|
Net Peak Torque (Since 2026)
|
1,100 rpm |
|
Net Peak Torque At Rated RPM (ISO 9249) (Since 2026)
|
513 lbs ft (696 nm)
|
|
Net Torque Rise (Since 2026)
|
40.0 % |
|
Non-Road Emission Standards (Since 2026)
|
EPA Final Tier 4/EU Stage V |
|
Valves Per Cylinder (Since 2026)
|
4 |
| General Specifications |
|
Bucket Capacity (Since 2024)
|
2.75–3.00 (2.1–2.3) |
|
Bucket Capacity (Since 2025)
|
2.75–3.00 |
|
Bucket Capacity (2026)
|
2.75–3.00 |
|
Engine Power (Since 2024)
|
166 hp (124 kw)
|
|
Engine Power Net (Since 2025)
|
168 hp (125 kw)
|
|
Engine Power Net (2026)
|
168 hp (125 kw)
|
|
Engine type (Since 2024)
|
Deere PowerTech PVS 6068 |
|
Engine type (2025)
|
Deere PowerTech PVS 6068 |
|
Engine type (Since 2026)
|
Deere PowerTech PSS 4045 |
|
Max Dump Height (Since 2024)
|
9 ft (3 m)
|
|
Max Dump Height (2025)
|
9 ft (3 m)
|
|
Max Dump Height (2026)
|
9 ft (3 m)
|
|
Operating Weight (Since 2024)
|
28,646–29,614 (12 993–13 443) |
|
Operating Weight (Since 2025)
|
28,646–29,886 |
|
OperatingWeight (Since 2026)
|
28,646–29,886 |
| Hydraulic System And Steering |
|
Hydraulic Dump Cycle Time (Since 2026)
|
1 s |
|
Hydraulic Lower (Power Down) Cycle Time (Since 2026)
|
3 s |
|
Hydraulic Raise Cycle Time (Since 2026)
|
6 s |
|
Hydraulic Total Cycle Time (Since 2026)
|
11 s |
|
Loader Controls (Since 2026)
|
2-function valve; joystick control or fingertip controls (field kit); hydraulic-function enable/disable; optional 3rd- and 4th-function valve with auxiliary lever |
|
Max Rated Flow At Rated RPM (Since 2026)
|
50 gpm (189 lpm)
|
|
Pump Type And System (Loader And Steering) (Since 2026)
|
Variable-displacement, axial-piston pump; closed-center, pressure-compensating system |
|
Rated RPM (Since 2026)
|
2,350 rpm |
|
Steering Articulation Angle Each Direction (Since 2026)
|
40 degrees |
|
Steering Articulation Full Arc Angle (Since 2026)
|
80 degrees |
|
Steering Type (ISO 5010) (Since 2026)
|
Steering-column mounted |
|
System Relief Pressure (Loader And Steering) (Since 2026)
|
3,650 psi |
|
Turning Radius (Measured To Centerline Of Outside Tire) (Since 2026)
|
16.4 ft, in. |
| Key Specs |
|
Net Peak Power (Since 2026)
|
1,800 rpm |
|
Net Peak Power At Rated RPM (ISO 9249) (Since 2026)
|
168 hp (125 kw)
|
|
Net Peak Torque (Since 2026)
|
1,100 rpm |
|
Net Peak Torque At Rated RPM (ISO 9249) (Since 2026)
|
513 lbs ft (696 nm)
|
| Serviceability |
|
Axle Oil Without Coolers (Front And Rear, Each) Refill Capacity (Since 2026)
|
4 gal (15 l)
|
|
Cooling System Refill Capacity (Since 2026)
|
30 qt |
|
Diesel-Exhaust Fluid (DEF) Refill Capacity (Since 2026)
|
15 qt |
|
Engine Oil With Vertical Spin-On Filter Refill Capacity (Since 2026)
|
20 qt |
|
Fuel Tank (With Lockable Cap) Refill Capacity (Since 2026)
|
76 gal (287 l)
|
|
Hydraulic Reservoir With Filter Refill Capacity (Since 2026)
|
23 gal (86 l)
|
|
Parking Brake Oil (Wet Disc) Refill Capacity (Since 2026)
|
10.0 oz. |
|
Transmission Reservoir With Vertical Filter Refill Capacity (Since 2026)
|
19 gal (72 l)
|
| Transmission System |
|
Operator Interface (Since 2026)
|
Joystick-mounted F-N-R; Quick-Shift button on hydraulic lever |
|
Shift Control (Since 2026)
|
Electronically modulated, adaptive, load and speed dependent |
|
Shift Modes (Since 2026)
|
Manual/auto (1st–D or 2nd–D); Quick-Shift button with 2 selectable modes: kick-down or kick-up/down; and 3 adjustable clutch cutoff settings |
|
Torque Converter (Since 2026)
|
Single stage, single phase |
|
Type (Since 2026)
|
Countershaft-type PowerShift™ |
| Wheels And Tires |
|
Tire Size Used To Measure (Since 2026)
|
Advance 20.5 R25, 2 Stars L-3 |
|
Tread Width On Standard Tires (Since 2026)
|
77 in (195 cm)
|
|
Width Over Tires On Standard Tires (Since 2026)
|
97 in (246 cm)
|
