| Backhoe |
|
Dig Depth - Ext |
18 ft (6 m)
|
|
Dig Depth - Std |
15 ft (4 m)
|
|
Load At Max Lift - Ext |
1,834 lbs (832 kg)
|
|
Load At Max Lift - Std |
3,270 lbs (1,483 kg)
|
|
Load Height - Ext |
14 ft (4 m)
|
|
Load Height - Std |
12 ft (4 m)
|
|
Reach From Swivel - Ext |
22 ft (7 m)
|
|
Reach From Swivel - Std |
19 ft (6 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height To Top Of Suspended Cab |
10 ft (3 m)
|
|
Transport Height |
14 ft (4 m)
|
|
Transport Length |
24 ft (7 m)
|
|
Transport Width |
8 ft (2 m)
|
|
Wheelbase |
7 ft (2 m)
|
| Engine |
|
Aspiration |
turbocharged |
|
Displacement |
275 cu in (4,506 cu cm)
|
|
Engine Make |
2,238 |
|
Engine Model |
S4D102LE-2 |
|
Gross Power |
93 hp (69 kw)
|
|
Net Max Torque |
300 lbs ft (407 nm)
|
|
Net Power |
89 hp (66 kw)
|
|
Number Of Cylinders |
4 |
|
Power Measured @ |
2,200 rpm |
|
Torque Measured @ |
1,500 rpm |
| General Specifications |
|
4TH GEAR FWD (Since 2010)
|
24 mph (38 kph)
|
|
BACKHOE LOADING HEIGHT (Since 2009)
|
12 ft (4 m)
|
|
BREAKOUT FORCE (Since 2010)
|
13,224 lbs (5,997 kg)
|
|
DIGGING DEPTH (Since 2010)
|
15 ft (4 m)
|
|
LIFT CAPACITY (Since 2010)
|
8,598 lbs (3,899 kg)
|
|
LOADER BREAKOUT FORCE (Since 2009)
|
13,224 lbs (5,997 kg)
|
|
LOADER LIFT CAPACITY (Since 2009)
|
8,598 lbs (3,899 kg)
|
|
LOADER SAE (Since 2009)
|
88 hp (66 kw)
|
|
LOADING HEIGHT (Since 2010)
|
12 ft (4 m)
|
|
MAX DIGGING DEPTH (Since 2009)
|
15 ft (4 m)
|
|
OPERATING WEIGHT (Since 2009)
|
16,240 lbs (7,365 kg)
|
|
SAE (Since 2010)
|
88 hp (66 kw)
|
|
TRAVEL SPEED 4TH GEAR FWD (Since 2009)
|
24 mph (38 kph)
|
|
WEIGHT (Since 2010)
|
16,240 lbs (7,365 kg)
|
| Hydraulic |
|
Pump Flow Capacity |
44 gpm (165 lpm)
|
|
Pump Type |
variable displacement piston |
|
Relief Valve Pressure |
3,553 psi |
| Loader |
|
Bucket Breakout Force |
13,224 lbs (5,997 kg)
|
|
Bucket Capacity |
1 cu yd |
|
Bucket Width |
93 in (236 cm)
|
|
Clearance At Max Dump Height |
9 ft (3 m)
|
|
Dig Depth |
5 in (14 cm)
|
|
Lift Capacity At Full Height |
8,598 lbs (3,899 kg)
|
|
Reach At Max Dump Height |
2 ft (1 m)
|
| Operational |
|
Alternator Supplied Amperage |
95 amps |
|
Cooling System Fluid Capacity |
4 gal (14 l)
|
|
Front Axle Fluid Capacity |
2 gal (7 l)
|
|
Fuel Capacity |
40 gal (150 l)
|
|
Hydraulic System Fluid Capacity |
26 gal (97 l)
|
|
Oil System Fluid Capacity |
2 gal (9 l)
|
|
Operating Voltage |
12 V |
|
Operating Weight 2wd |
16,094 lbs (7,299 kg)
|
|
Operating Weight 4wd |
16,094 lbs (7,299 kg)
|
|
Rear Axle Fluid Capacity |
4 gal (15 l)
|
|
Rear Tires Size 2wd/4wd |
19.5 x 24 10ply R4 |
|
Tire Size Front - 2wd / 4wd |
14 x 17.5 10ply R4 |
|
Transmission Fluid Capacity |
5 gal (20 l)
|
|
Turning Radius |
11 ft (3 m)
|
| Transmission |
|
Max Speed - Forward |
24 mph (38 kph)
|
|
Max Speed Reverse |
24 mph (38 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
4 |
|
Transmission Type |
synchronized gearbox, powershift shuttle |
