| Backhoe |
|
Arm Breakout Force (Iso 6015) |
9 lbs (4 kg)
|
|
Bucket Breakout Force (Iso 6015) |
13 lbs (6 kg)
|
|
Bucket Dig Force - Std |
13,444 lbs (6,098 kg)
|
|
Dig Depth - Ext |
20 ft (6 m)
|
|
Dig Depth - Std |
15 ft (5 m)
|
|
Load At Max Lift - Std |
3,307 lbs (1,500 kg)
|
|
Load Height - Ext |
16 ft (5 m)
|
|
Load Height - Std |
14 ft (4 m)
|
|
Reach From Swivel - Ext |
22 ft (7 m)
|
|
Reach From Swivel - Std |
19 ft (6 m)
|
| Brakes |
|
Disc Diameter |
1 ft (0 m)
|
| Dimensions |
|
Transport Height |
12 ft (4 m)
|
|
Transport Length |
19 ft (6 m)
|
|
Transport Width |
8 ft (2 m)
|
| Engine |
|
Air Filter Type |
Dry filter with safety element |
|
Aspiration |
turbo-inter cooled |
|
Bore |
4 in (10 cm)
|
|
Combustion |
Direct injection (DI) |
|
Cooling System |
radiator |
|
Displacement |
273,692 cu in (4,485,012 cu cm)
|
|
Engine Make |
2,238 |
|
Engine Model |
Komatsu S4D104E-3 |
|
Engine Power@Iso 14396 |
992 hp (740 kw)
|
|
Engine Type |
vertical, 4-cycle water-cooled diesel engine |
|
Gross Power |
99 hp (74 kw)
|
|
Max Torque |
310 lbs ft (420 nm)
|
|
Number Of Cylinders |
4 |
|
Starting System |
Electric motor with per-heating air system for cold climate |
|
Stroke |
5 in (13 cm)
|
| Environment |
|
Body |
? 0,5 m/s² (uncertainty K = 0,2 m/s² |
|
Hand/Arm |
? 2,5 m/s² (uncertainty K = 1,2 m/s²) |
|
Vibration Levels |
(EN 12096:1997)* |
| Hydraulic |
|
Pump Flow Capacity |
44 gpm (165 lpm)
|
|
Pump Type |
VDAP |
|
Relief Valve Pressure |
3,626 psi |
| Hydraulic System |
|
Hydraulic System Type |
Closed Load Sensing System, CLSS |
|
Main Valve |
LIFD “Load Independent Flow Divider” modular type |
|
Max Delivery |
44 gpm (165 lpm)
|
|
Pump Type |
variable displacement axial pistons |
|
Pumps Control System |
Load Sensing |
|
System |
SyncroSystem |
| Loader |
|
4×1 Bucket Capacity (Iso 7546) |
1.0m3 |
|
4×1 Bucket Width |
0 ft |
|
Breakout Force (Iso 14397) |
14 lbs (7 kg)
|
|
Bucket Breakout Force |
_ - |
|
Bucket Capacity |
1 cu yd |
|
Bucket Width |
91 in (232 cm)
|
|
Clearance At Max Dump Height |
9 ft (3 m)
|
|
Lift Capacity At Full Height |
8,598 lbs (3,900 kg)
|
|
Lifting Capacity At Ground Level (Iso 14397) |
12 lbs (5 kg)
|
|
Lifting Capacity At Maximum Height |
9 lbs (4 kg)
|
|
Standard Bucket Capacity (Iso 7546) |
1.03m3 |
|
Standard Bucket Width |
0 ft |
|
Std Bucket Weight |
948 lbs (430 kg)
|
| Operational |
|
Fuel Capacity |
40 gal (150 l)
|
|
Operating Weight 4wd |
16,447 lbs (7,460 kg)
|
| Refils |
|
Cooling System |
1,007 cu in (16,500 cu cm)
|
|
Engine Oil |
781 cu in (12,802 cu cm)
|
|
Front Axle Oil |
519 cu in (8,502 cu cm)
|
|
Fuel Tank |
9,154 cu in (150,001 cu cm)
|
|
Gearbox Oil |
976 cu in (16,000 cu cm)
|
|
Hydraulic Oil System Capacity |
5,919 cu in (97,002 cu cm)
|
|
Hydraulic Oil Tank |
2,502 cu in (41,001 cu cm)
|
|
Rear Axle Oil |
885 cu in (14,501 cu cm)
|
| Steering System |
|
Turning Radius (Using Brakes)_ At Outer Edge Of Front Tyre |
10,499 ft (3,200 m)
|
|
Turning Radius (Using Brakes)_ At The Corner Of The Bucket) |
16 ft (5 m)
|
|
Turning Radius W/O Brakes At Outer Edge Of Front Tyre |
14 ft (4 m)
|
|
Turning Radius(Without Using Brakes)_At Outer Edge Of Front Tyre |
13 ft (4 m)
|
| Transmission |
|
Max Speed - Forward |
25 mph (40 kph)
|
|
Max Speed Reverse |
25 mph (40 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
4 |
|
Transmission Type |
power shuttle |
| Tyres |
|
Standard_Front |
12.5/80 R18 - 10 PR |
|
Standard_Option_Front |
365/70 R18; 320/80 R18 IT 530; 12.5 - 20 MPT 10 PR |
|
Standard_Option_Rear |
18.4 × 26 - 12 PR; 440/80 R28 IT 530; 16.9 - 30 IND 10 PR |
|
Standard_Rear |
16.9 × 28 - 12 PR |
| Weights |
|
Operating Weight |
17,571 lbs (7,970 kg)
|
|
Operating Weight Increase_ Forks For 4×1 Bucket |
150 |
|
Operating Weight Increase_ Pallet Forks |
-280 |
|
Operating Weight Increase_ Standard Arm |
-260 |
|
Operating Weight Increase_Offset Boom |
190 |
|
Operating Weight Increase_Standard Bucket |
-300 |
|
Standard Machine Operating Weight |
18 lbs (8 kg)
|
|
Total Machine Weight |
20 lbs (9 kg)
|
