| Bucket |
|
Breakout Force |
24,581 lbs (11,150 kg)
|
|
Breakout Force |
24,504 lbs (11,115 kg)
|
|
Bucket Capacity - Heaped |
2 cu yd |
|
Bucket Capacity - Struck |
2 cu yd |
|
Bucket Capacity - Struck |
2 cu yd |
|
Bucket Width |
8 ft (3 m)
|
|
Dump Clearance At Max Raise |
9 ft (3 m)
|
| Dimensions |
|
Dump Clearance At Max Lift |
9 ft (3 m)
|
|
Ground Clearance |
2 ft (0 m)
|
|
Ground Clearance |
2 ft (1 m)
|
|
Height To Top Of Cab |
10 ft (3 m)
|
|
Height To Top Of Cab |
10 ft (3 m)
|
|
Hinge Pin - Max Height |
13 ft (4 m)
|
|
Hook Height At Max Lift - Extended |
24 ft (7 m)
|
|
Hook Height At Max Lift - Standard |
22 ft (7 m)
|
|
Hook Reach At Max Lift - Extended |
10 ft (3 m)
|
|
Hook Reach At Max Lift - Standard |
9 ft (3 m)
|
|
Length W/ Bucket On Ground |
24 ft (7 m)
|
|
Length With Bucket On Ground |
25 ft (8 m)
|
|
Length With Out Forks On Ground |
25 ft (8 m)
|
|
Max Lift Height |
12 ft (4 m)
|
|
Reach At Max Height And Dump |
4 ft (1 m)
|
|
Reach At Max Lift And Dump |
3 ft (1 m)
|
|
Wheelbase |
9 ft (3 m)
|
|
Wheelbase |
9 ft (3 m)
|
|
Width Over Tires |
8 ft (2 m)
|
|
Width Over Tires |
8 ft (2 m)
|
| Engine |
|
Aspiration |
turbocharged |
|
Aspiration |
turbocharged, and air-to-air aftercooled |
|
Displacement |
365 cu in (5,981 cu cm)
|
|
Displacement |
359 cu in (5,883 cu cm)
|
|
Engine Make |
2,238 |
|
Engine Make |
2,238 |
|
Engine Model |
SAA6D102E-2 |
|
Engine Model |
SAA6D102E-2 |
|
Gross Power |
127 hp (95 kw)
|
|
Gross Power |
127 hp (95 kw)
|
|
Net Power |
120 hp (89 kw)
|
|
Net Power |
120 hp (89 kw)
|
|
Number Of Cylinders |
6 |
|
Power Measured @ |
2,000 rpm |
| Hydraulic System |
|
Dump Time |
2 sec |
|
Dump Time |
2 sec |
|
Lower Time |
4 sec |
|
Lower Time |
4 sec |
|
Pump Flow Capacity |
41 gpm (156 lpm)
|
|
Pump Type |
gear-typ |
|
Raise Time |
6 sec |
|
Raise Time |
6 sec |
|
Relief Valve Setting |
2,900 psi |
|
Relief Valve Setting |
3,000 psi |
| Operational |
|
Alternator Supplied Amperage |
60 amps |
|
Cooling System Fluid Capacity |
5 gal (17 l)
|
|
Engine Oil Capacity |
6 gal (21 l)
|
|
Engine Oil Fluid Capacity |
5 gal (20 l)
|
|
Front Axle/Diff Fluid Capacity |
5 gal (18 l)
|
|
Front Diff Fluid Capacity |
5 gal (18 l)
|
|
Fuel Capacity |
49 gal (184 l)
|
|
Fuel Capacity |
49 gal (184 l)
|
|
Hydraulic System Fluid Capacity |
18 gal (67 l)
|
|
Hydraulic System Fluid Capacity |
18 gal (67 l)
|
|
Operating Voltage |
24 V |
|
Operating Weight |
22,771 lbs (10,329 kg)
|
|
Rear Axle Oscillation |
24 degrees |
|
Rear Axle/Diff Fluid Capacity |
5 gal (18 l)
|
|
Rear Diff Fluid Capacity |
5 gal (18 l)
|
|
Static Tipping Load - Bucket |
2 lbs (1 kg)
|
|
Static Tipping Load - Forks |
13,012 lbs (5,902 kg)
|
|
Static Tipping Load - Material Handler |
6,816 lbs (3,092 kg)
|
|
Static Tipping Weight |
16,852 lbs (7,644 kg)
|
|
Tire Size |
20.5/25-12PR (L2) |
|
Tire Size |
20.5/25 L2 |
|
Transmission Fluid Capacity |
2 gal (6 l)
|
|
Turning Radius |
16 ft (5 m)
|
|
Turning Radius |
16 ft (5 m)
|
| Transmission |
|
Max Speed - Forward |
24 mph (38 kph)
|
|
Max Speed - Reverse |
24 mph (38 kph)
|
|
Max Speed Forward |
24 mph (38 kph)
|
|
Max Speed Reverse |
24 mph (38 kph)
|
|
Number Of Forward Gears |
2 |
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
4 |
|
Number Of Reverse Gears |
2 |
|
Transmission Type |
hydrostatic |
|
Transmission Type |
Hydrostatic, 1 pump, 2 motors with speed range select |
