| Bucket |
|
Breakout Force |
35,494 lbs (16,100 kg)
|
|
Bucket Capacity - heaped |
4 cu yd (3 cu m)
|
|
Bucket Capacity - struck |
4 cu yd (3 cu m)
|
|
Bucket Width |
10 ft (3 m)
|
|
Dump Clearance at Max Raise |
10 ft (3 m)
|
| Dimensions |
|
Ground Clearance |
2 ft (0 m)
|
|
Height - Top of Cab |
11 ft (3 m)
|
|
Hinge Pin - Max Height |
14 ft (4 m)
|
|
Length with Bucket on Ground |
27 ft (8 m)
|
|
Reach at Max Lift and Dump |
4 ft (1 m)
|
|
Wheelbase |
11 ft (3 m)
|
|
Width Over Tires |
9 ft (3 m)
|
| Engine |
|
Air cleaner |
Dry type with double elements |
|
Aspiration |
Turbocharged |
|
Bore |
4 in (11 cm)
|
|
Displacement |
408 cu in (6,691 cu cm)
|
|
Emissions Certification |
EPA Tier 4 |
|
Engine Model |
SAA6D107E-3 |
|
Gross Power |
192 hp (143 kw)
|
|
Net Power |
191 hp (142 kw)
|
|
Number of Cylinders |
6 |
|
Stroke |
5 in (12 cm)
|
|
Torque Measured @ |
2,100 rpm |
| General Specifications |
|
Bucket Capacity (Since 2016)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Bucket Capacity (2017)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Bucket Capacity (2019)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Bucket Capacity (2020)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Bucket Capacity (2021)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Bucket Capacity (2022)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Bucket Capacity (2023)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Bucket Capacity (2024)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Bucket Capacity cu. yd. (cu m) (Since 2025)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Bucket Capacity cu. yd. (cu m) (2026)
|
3.5 - 4.3 (2.7 - 3.3) |
|
Engine Power (Since 2016)
|
191 (142) |
|
Engine Power (2017)
|
191 (142) |
|
Engine Power (Since 2019)
|
191 (143) |
|
Engine Power (2020)
|
191 (143) |
|
Engine Power (2021)
|
191 (143) |
|
Engine Power (2022)
|
191 (143) |
|
Engine Power (2023)
|
191 (143) |
|
Engine Power (2024)
|
191 (143) |
|
Engine Power Net hp (kW) (Since 2025)
|
191 (143) |
|
Engine Power Net hp (kW) (2026)
|
191 (143) |
|
Engine type (Since 2016)
|
SAA6D107E-3 |
|
Engine type (2017)
|
SAA6D107E-3 |
|
Engine type (2019)
|
SAA6D107E-3 |
|
Engine type (2020)
|
SAA6D107E-3 |
|
Engine type (2021)
|
SAA6D107E-3 |
|
Engine type (2022)
|
SAA6D107E-3 |
|
Engine type (2023)
|
SAA6D107E-3 |
|
Engine type (2024)
|
SAA6D107E-3 |
|
Engine type (2025)
|
SAA6D107E-3 |
|
Engine type (2026)
|
SAA6D107E-3 |
|
Max Dump Height (Since 2016)
|
9.7 (2.9) |
|
Max Dump Height (2017)
|
9.7 (2.9) |
|
Max Dump Height (2019)
|
9.7 (2.9) |
|
Max Dump Height (2020)
|
9.7 (2.9) |
|
Max Dump Height (2021)
|
9.7 (2.9) |
|
Max Dump Height (2022)
|
9.7 (2.9) |
|
Max Dump Height (2023)
|
9.7 (2.9) |
|
Max Dump Height (2024)
|
9.7 (2.9) |
|
Max Dump Height ft.( m) (Since 2025)
|
9.7 (2.9) |
|
Max Dump Height ft.( m) (Since 2026)
|
9.8 (2.9) |
|
Operating Weight (Since 2016)
|
40,532 - 40,932 (18385 - 19020) |
|
Operating Weight (2017)
|
40,532 - 40,932 (18385 - 19020) |
|
Operating Weight (Since 2019)
|
40,532 - 41,932 (18,385 - 19,020) |
|
Operating Weight (Since 2020)
|
40,532 - 41,932 (18385 - 19020) |
|
Operating Weight (2021)
|
40,532 - 41,932 (18385 - 19020) |
|
Operating Weight (2022)
|
40,532 - 41,932 (18385 - 19020) |
|
Operating Weight (Since 2023)
|
40,532 - 41,932 (18,385 - 19,020) |
|
Operating Weight (2024)
|
40,532 - 41,932 (18,385 - 19,020) |
|
Operating Weight lbs. (kg) (Since 2025)
|
40,532 - 41,932 (18,385 - 19,020) |
|
OperatingWeight lbs. (kg) (Since 2026)
|
40,532 - 41,932 (18,385 - 19,020) |
| Hydraulic System |
|
Dump Time |
2 seconds |
|
Lower Time |
3 seconds |
|
Pump Flow Capacity |
36 gpm (137 lpm)
|
|
Pump Type |
Piston pump |
|
Raise Time |
6 seconds |
|
Relief Valve Pressure |
4,550 psi |
| Operating Specifications |
|
Alternator Supplied Amperage |
90 amps |
|
Cooling System Fluid Capacity |
16 gal (61 l)
|
|
Engine Oil Fluid Capacity |
6 gal (23 l)
|
|
Front Axle/Diff Fluid Capacity |
11 gal (40 l)
|
|
Fuel Capacity |
79 gal (300 l)
|
|
Hydraulic System Fluid Capacity |
38 gal (142 l)
|
|
Operating Voltage |
24 volts |
|
Operating Weight |
40,686 lbs (18,455 kg)
|
|
Rated Bucket Capacity |
4 - 4 cu yd (3 - 3 cu m)
|
|
Rear Axle/Diff Fluid Capacity |
11 gal (40 l)
|
|
Static Tipping Weight |
34,039 lbs (15,440 kg)
|
|
Transmission Fluid Capacity |
14 gal (54 l)
|
| Transmission |
|
Max Speed - Forward |
23 mph (38 kph)
|
|
Max Speed - Reverse |
24 mph (39 kph)
|
|
Number of Forward Gears |
4 |
|
Number of Reverse Gears |
4 |
|
Transmission Type |
Automatic |
| Weights |
|
Operational Weight |
40,532 - 40,929 lbs (18,385 - 18,565 kg)
|
