| Boom/Stick Mat. Handler Option 1 |
|
Boom/Stick Option (MAT) 1 |
6.8m boom / 5m stick |
|
Max Depth |
11 ft (3 m)
|
|
Max Height |
43 ft (13 m)
|
|
Max Reach Along Ground |
38 ft (12 m)
|
| Boom/Stick Mat. Handler Option 2 |
|
Boom/Stick Option (MAT) 2 |
6.8m boom / 6m stick |
|
Max Depth |
14 ft (4 m)
|
|
Max Height |
46 ft (14 m)
|
|
Max Reach Along Ground |
41 ft (13 m)
|
| Boom/Stick Mat. Handler Option 3 |
|
Boom/Stick Option (MAT) 3 |
6.8m boom / 5m stick and grapple model 65 |
|
Max Depth |
20 ft (6 m)
|
|
Max Height |
36 ft (11 m)
|
|
Max Reach Along Ground |
42 ft (13 m)
|
| Boom/Stick Mobile Excavator Option 1 |
|
Max Cutting Height |
35 ft (11 m)
|
|
Max Digging Depth |
20 ft (6 m)
|
|
Max Loading Height |
25 ft (8 m)
|
|
Max Reach Along Ground |
31 ft (9 m)
|
|
Max Vertical Wall Dig Depth |
14 ft (4 m)
|
|
Shipping Height of Unit |
11 ft (3 m)
|
|
Shipping Length of Unit |
32 ft (10 m)
|
| Boom/Stick Mobile Excavator Option 2 |
|
Max Cutting Height |
36 ft (11 m)
|
|
Max Digging Depth |
20 ft (6 m)
|
|
Max Loading Height |
25 ft (8 m)
|
|
Max Reach Along Ground |
32 ft (10 m)
|
|
Max Vertical Wall Dig Depth |
15 ft (4 m)
|
|
Shipping Height of Unit |
11 ft (3 m)
|
|
Shipping Length of Unit |
32 ft (10 m)
|
| Boom/Stick Mobile Excavator Option 3 |
|
Max Cutting Height |
36 ft (11 m)
|
|
Max Digging Depth |
21 ft (6 m)
|
|
Max Loading Height |
26 ft (8 m)
|
|
Max Reach Along Ground |
32 ft (10 m)
|
|
Max Vertical Wall Dig Depth |
15 ft (5 m)
|
|
Shipping Height of Unit |
11 ft (3 m)
|
|
Shipping Length of Unit |
32 ft (10 m)
|
| Boom/Stick Mobile Excavator Option 4 |
|
Max Cutting Height |
37 ft (11 m)
|
|
Max Digging Depth |
22 ft (7 m)
|
|
Max Loading Height |
27 ft (8 m)
|
|
Max Reach Along Ground |
34 ft (10 m)
|
|
Max Vertical Wall Dig Depth |
16 ft (5 m)
|
|
Shipping Height of Unit |
11 ft (3 m)
|
|
Shipping Length of Unit |
32 ft (10 m)
|
| Bucket |
|
Maximum Bucket Capacity |
2 cu yd (1 cu m)
|
|
Minimum Bucket Capacity |
1 cu yd (0 cu m)
|
| Dimensions |
|
Overall Width |
9 in (23 cm)
|
|
Overall Width - Outriggers Down |
14 ft (4 m)
|
|
Shipping Height |
11 ft (3 m)
|
|
Shipping Length |
33 ft (10 m)
|
|
Undercarriage Width |
9 ft (3 m)
|
|
Upper Structure Clearance |
4 ft (1 m)
|
|
Upperstructure Clearance |
5 ft (1 m)
|
|
Wheelbase |
9 ft (3 m)
|
| Engine |
|
Aspiration |
turbo-charged and after-cooled reduced emissions |
|
Displacement |
427 cu in (7,001 cu cm)
|
|
Engine Model |
D 934 L |
|
Gross Power |
184 hp (137 kw)
|
|
Net Power |
184 hp (137 kw)
|
|
Number of Cylinders |
4 |
|
Power Measured @ |
1,800 rpm |
| Hydraulic System |
|
Pump Capacity |
57 gpm (215 lpm)
|
|
Pump Type |
Liebherr variable displacement swash plate double pump |
| Operating Specifications |
|
Alternator Supplied Amperage |
80 amps |
|
Fuel Capacity |
106 gal (400 l)
|
|
Hydraulic Pump Flow Capacity |
57 gpm (215 lpm)
|
|
Hydraulic System Fluid Capacity |
114 gal (430 l)
|
|
Hydraulic System Relief Valve Pressure |
5,076 psi |
|
Operating Weight |
56,400 lbs (25,583 kg)
|
|
Operating Weight w/o Attachment |
46,100 lbs (20,911 kg)
|
|
Tire Size |
11.00-20 |
| Swing Mechanism |
|
Swing Speed |
8 rpm |
| Transmission |
|
Max Speed |
13 mph (20 kph)
|
|
Max Travel Speed |
13 mph (20 kph)
|
|
Transmission Type |
oversized two speed power shift transmission with additional creeper speed |
| Wheel Undercarriage |
|
Steering Angle |
30 degrees |
|
Tire Size |
11.00-20 |
|
Wheelbase |
9 ft (3 m)
|
|
Width w/ Stabilizers on Ground |
14 ft (4 m)
|
