2006 Link-Belt HTC-8690 For Sale in Harrisburg, PA

Name: 2006 Link-Belt HTC-8690
Brand: Link-Belt
SKU: 89315538
Price: 125000 USD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $125,000.00 USD

Apply for Financing

Stephenson Equipment, Inc.

Stephenson Equipment, Inc. Dealer Info

Stephenson Equipment, Inc. Website

Click here to email Stephenson Equipment, Inc..

Contact: Kyle Hoffman

Click for Phone Number

Machine Info:

Hours:	20000
Stock Number:	N3J6-8257
Machine Location:	HARRISBURG, PA
More Information:	https://stephensonequipmentjcb.com/inventory/cranes+-+truck+cranes+-+telescopic+boom/2006-link-belt-htc-8690-harrisburg-pa-6ab3db90ff094add420b011c/

Description:

2006 LINK-BELT, HTC-8690 Cranes - Truck Cranes - Telescopic Boom, 90 Ton Capacity. 140’ Main Boom, 35-58’ Jib. 205’ Total Tip Height, Aux. Winch, Overhaul Weight, 4 Out-and-Down Outriggers with front stabilizer. Heat in upper cab. 455 HP Detroit Diesel Series 60 Engine. Block Heater. Engine Brake. ZF AS---TRONIC (no clutch pedal) manual transmission with 12 forward gears and 2 reverse gears. Air Ride Suspension. *Stephenson Equipment has a large inventory spread out across 10 locations in PA & NY. Please contact us before coming to inspect a piece of equipment.

From the manufacturer:

Supplied by HeavyEquipmentData.com →

Boom
Max Elevating Angle	80 degrees
Max Height @ Max Raise Angle - No Jib	148 ft (45 m)
Max Lift Capacity	164,400 lbs (74,571 kg)
Max Working Radius	130 ft (40 m)
Min Height @ Max Raise Angle	47 ft (14 m)
Min Working Radius	9 ft (3 m)
Number Of Sections	5
Swing Speed	2 rpm
Carrier Engine
Displacement	763 cu in (12,500 cu cm)
Gross Power	445 hp (332 kw)
Make	Link-Belt
Max Torque	1,550 lbs ft (2,101 nm)
Power Measured @	1,800 rpm
Torque Measured @	1,200 rpm
Dimensions
Carrier Length	38 ft (11 m)
Ground Clearance	1 ft (0 m)
Transport Height	12 ft (4 m)
Transport Length	46 ft (14 m)
Transport Width	9 ft (3 m)
Upper Structure Tail Swing Radius	14 ft (4 m)
Wheelbase	23 ft (7 m)
Width W/ Outriggers Extended	26 ft (8 m)
Operational
Alternator Supplied Amperage	135 amps
Carrier Fuel Capacity	95 gal (360 l)
Carrier Hydraulic System Fluid Capacity	144 gal (545 l)
Carrier Oil Capacity	11 gal (40 l)
Fuel Capacity	95 gal (360 l)
Number Of Axels	4
Operating Voltage	12 V
Operating Weight	79,533 lbs (36,076 kg)
Tire Size	445/65r22.5, rear 12R22.5
Transmission
Max Speed - Forward	62 mph (100 kph)
Max Speed - Reverse	6 mph (9 kph)
Number Of Forward Gears	12
Number Of Reverse Gears	2
Transmission Type	manual transmission
Upper Structure Engine
Displacement	915 cu in (14,994 cu cm)
Gross Power	480 hp (358 kw)
Make	Link-Belt
Max Torque	1,550 lbs ft (2,102 nm)
Power Measured @	1,800 rpm
Torque Measured @	1,400 rpm
