Takeuchi TL140 For Sale in Denver, Co

Name: Takeuchi TL140
Brand: Takeuchi
SKU: 89354637
Availability: InStock

❮

❯

/ Save to Watch List

Apply for Financing

Auction Pricing

Auction Info: Starting on 2026-10-21 Click here to place a bid

Ritchie Bros. Auctioneers

Ritchie Bros. Auctioneers Dealer Info

Ritchie Bros. Auctioneers Website

Click here to email Ritchie Bros. Auctioneers.

Click for Phone Number

Machine Info:

Serial Number:	21404874
Machine Location:	DENVER, CO

Description:

From the manufacturer:

Supplied by HeavyEquipmentData.com →

Dimensions
Clearance At Full Height And Dump	8 ft (2 m)
Clearance At Max Lift And Dump	10 ft (3 m)
Ground Clearance	13 in (33 cm)
Height To Top Of Cab	7 ft (2 m)
Length With Bucket	12 ft (4 m)
Length With Bucket On Ground	8 ft (2 m)
Reach At Dump Height	3 ft (1 m)
Reach At Max Lift And Dump	3 ft (1 m)
Turning Radius From Center - Inc Bucket	90 in (229 cm)
Turning Radius From Center - Machine Rear	66 in (167 cm)
Width Over Tracks	6 ft (2 m)
Engine
Displacement	4 cu in (66 cu cm)
Displacement	188 cu in (3,076 cu cm)
Engine Make	2,353
Engine Make	2,353
Engine Model	4JG1T
Engine Model	4JG1T
Gross Power	81 hp (60 kw)
Number Of Cylinders	4
Peak Torque	193 lbs ft (262 nm)
Power Measured @	2,500 rpm
Torque Measured @	1,800 rpm
Hydraulic
Dump Time	3 sec
Lower Time	3 sec
Pump Flow	20 gpm (75 lpm)
Raise Time	4 sec
Relief Valve Pressure	2,988 psi
Loader
Breakout Force	7,403 lbs (3,358 kg)
Operating Load	2,083 lbs (945 kg)
Tipping Angle	5,952 degrees
Operational
Alternator Supplied Amperage	50 amps
Alternator Supplied Amperage	50 amps
Breakout Force - Std Bucket	7,403 lbs (3,358 kg)
Cooling System Fluid Capacity	4 gal (15 l)
Cooling System Fluid Capacity	15 gal (58 l)
Engine Oil Capacity	3 gal (10 l)
Engine Oil Capacity	10 gal (36 l)
Fuel Capacity	24 gal (90 l)
Fuel Capacity	24 gal (90 l)
Hydraulic System Fluid Capacity	14 gal (52 l)
Hydraulic System Fluid Capacity	14 gal (52 l)
Max Speed	5 mph (7 kph)
Max Speed - High Range	7 mph (11 kph)
Max Speed - Low Range	5 mph (7 kph)
Operating Voltage	12 V
Operating Voltage	12 V
Operating Weight	9,590 lbs (4,350 kg)
Operating Weight	9,769 lbs (4,431 kg)
Static Tipping Load	5,952 lbs (2,700 kg)
Undercarriage
Ground Pressure	4 psi
Ground Pressure	4 psi
Length Of Track On Ground	5 ft (2 m)
Length Of Track On Ground	5 ft (2 m)
Number Of Track Rollers Per Side	5
Number Of Track Rollers Per Side	5
Width Of Track	18 in (46 cm)
