| Bucket |
|
Breakout Force, Curl |
7,187 lbs (3,260 kg)
|
|
Breakout Force, Lift |
5,807 lbs (2,634 kg)
|
|
General Purpose Bucket Heaped Cap |
1 cu yd |
|
General Purpose Bucket Height |
2 ft (1 m)
|
|
General Purpose Bucket Length |
3 ft (1 m)
|
|
General Purpose Bucket Weight |
576 lbs (261 kg)
|
|
General Purpose Bucket Width |
7 ft (2 m)
|
|
Landscape Bucket Heaped Cap |
1 cu yd |
|
Landscape Bucket Height |
2 ft (1 m)
|
|
Landscape Bucket Length |
3 ft (1 m)
|
|
Landscape Bucket Weight |
0.5 in2 |
|
Landscape Bucket Width |
7 ft (2 m)
|
|
Multi Purpose Bucket Heaped Cap |
1 cu yd |
|
Multi Purpose Bucket Height |
2 ft (1 m)
|
|
Multi Purpose Bucket Length |
3 ft (1 m)
|
|
Multi Purpose Bucket Weight |
884 lbs (401 kg)
|
|
Multi Purpose Bucket Width |
7 ft (2 m)
|
| Capacities |
|
Cooling System |
4 gal (16 l)
|
|
Engine Oil W/ Filter Change |
4 gal (15 l)
|
|
Fuel Tank |
27 gal (103 l)
|
|
Hydraulic Oil Reservoir |
7 gal (26 l)
|
|
Hydraulic System |
16 gal (60 l)
|
|
Tipping Load |
8,627 lbs (3,913 kg)
|
| Dimensions |
|
Angle Of Departure |
29 degrees |
|
Attachment Roll Back Angle |
30 degrees |
|
Clearance At Max Lift And Dump |
8 ft (2 m)
|
|
Dump Angle |
42 degrees |
|
Dump Height |
8 ft (2 m)
|
|
Dump Reach |
35 in (90 cm)
|
|
Ground Clearance |
10 in (25 cm)
|
|
Ground Clearance |
9 in (23 cm)
|
|
Height To Hinge Pin |
125 in (318 cm)
|
|
Height To Top Of Cab |
7 ft (2 m)
|
|
Length With Bucket |
12 ft (4 m)
|
|
Length With Out Bucket |
9 ft (3 m)
|
|
Overall Height |
7 ft (2 m)
|
|
Overall Length (L/Bucket) |
10 ft (3 m)
|
|
Overall Length (W/Bucket) |
12 ft (4 m)
|
|
Reach At Max Lift And Dump |
3 ft (1 m)
|
|
Turning Radius |
6 ft (2 m)
|
|
Turning Radius From Center - Inc Bucket |
69 in (176 cm)
|
|
Turning Radius From Center - Machine Rear |
69 in (176 cm)
|
|
Turning Radius Front L/Bucket |
5 ft (1 m)
|
|
Turning Radius Front W/Bucket |
8 ft (2 m)
|
|
Wheelbase |
6 ft (2 m)
|
|
Width Over Tracks |
7 ft (2 m)
|
| Engine |
|
Alternator |
342000 amps |
|
Aspiration |
Turbocharged |
|
Aspiration |
Turbo |
|
Battery |
12 - 109 (V - Ah) |
|
Displacement |
268 cu in (4,392 cu cm)
|
|
Displacement |
151 cu in (2,481 cu cm)
|
|
Engine Make |
2,257 |
|
Engine Model |
TC63 |
|
Engine Model |
TCAE - 55 |
|
Fuel Type |
Diesel |
|
Gross Horsepower – Sae J1995 |
74 hp (55 kw)
|
|
Gross Power |
92 hp (69 kw)
|
|
Max Torque |
295 lbs ft (400 nm)
|
|
Net Power |
92 hp (69 kw)
|
|
Net Power |
73 hp (54 kw)
|
|
Number Of Cylinders |
4 |
|
Number Of Cylinders |
4 |
|
Peak Torque |
301 lbs ft (408 nm)
|
|
Power Measured @ |
2,200 rpm |
|
Starter |
6 hp (4 kw)
|
|
Torque Measured @ |
1,800 rpm |
| General Specifications |
|
ENGINE POWER (Since 2016)
|
92 hp (69 kw)
|
|
ENGINE POWER (2017)
|
92 hp (69 kw)
|
|
MODEL (Since 2016)
|
MCT135C |
|
MODEL (2017)
|
MCT135C |
|
OPERATING LOAD (Since 2016)
|
3,000 lbs (1,361 kg)
|
|
OPERATING LOAD (2017)
|
3,000 lbs (1,361 kg)
|
|
OPERATING WIDTH (Since 2016)
|
78 in (198 cm)
|
|
OPERATING WIDTH (2017)
|
78 in (198 cm)
|
| Hydraulic |
|
Pump Flow |
23 gpm (87 lpm)
|
|
Relief Valve Pressure |
3,335 psi |
| Loader |
|
Bucket Capacity |
1 cu yd |
|
Bucket Width |
78 in (198 cm)
|
|
Bucket Width |
84 in (213 cm)
|
|
High Flow Pump Output |
33 gpm (125 lpm)
|
|
Operating Load |
3,000 lbs (1,361 kg)
|
|
Standard Hydraulic Pump Output |
24 gpm (90 lpm)
|
|
System Pressure |
3,335 psi |
|
Tipping Angle |
8,628 degrees |
| Operational |
|
Alternator Supplied Amperage |
95 amps |
|
Cooling System Fluid Capacity |
4 gal (16 l)
|
|
Engine Oil Capacity |
4 gal (15 l)
|
|
Fuel Capacity |
27 gal (103 l)
|
|
Hydraulic System Fluid Capacity |
16 gal (60 l)
|
|
Max Speed - High Range |
8 mph (13 kph)
|
|
Max Speed - Low Range |
6 mph (9 kph)
|
|
Operating Voltage |
12 V |
|
Operating Weight |
10,663 lbs (4,837 kg)
|
| Performance |
|
Curl |
2 sec |
|
Dump |
2 sec |
|
Lift Arm Path |
Vertical |
|
Lower (Power Down) |
4 sec |
|
Raise (Lifting) |
5 sec |
|
Rated Operating Load, 35% Tip |
3,001 lbs (1,361 kg)
|
| Speeds |
|
Single Speed |
6 mph (9 kph)
|
| Undercarriage |
|
Width Of Track |
18 in (45 cm)
|
| Weights |
|
Weight |
11,288 lbs (5,120 kg)
|
