| Body |
|
Plate Thickness-Bottom |
1 in (2 cm)
|
|
Plate Thickness-Chute |
1 in (2 cm)
|
|
Plate Thickness-Front |
0 in (1 cm)
|
|
Plate Thickness-Sides |
0 in (1 cm)
|
| Capacities |
|
Brake Cooling System |
9 gal (35 l)
|
|
Cooling System |
13 gal (48 l)
|
|
Crankcase |
9 gal (35 l)
|
|
Def Tank |
10 gal (39 l)
|
|
Dropbox |
2 gal (9 l)
|
|
Fuel Tank |
100 gal (380 l)
|
|
Hydraulic Tank |
36 gal (137 l)
|
|
Transmission |
11 gal (41 l)
|
| Dimensions |
|
Dump Ground Clearance |
2 ft (1 m)
|
|
Dump Height |
22 ft (7 m)
|
|
Ground Clearance |
2 ft (1 m)
|
|
Overall Height |
11 ft (3 m)
|
|
Overall Length |
34 ft (10 m)
|
|
Overall Width |
18 ft (5 m)
|
|
Wheelbase |
9 ft (3 m)
|
| Drive Train |
|
Axles |
AHW64 |
|
Dropbox |
IL1 ATC |
|
Torque Converter |
2.37:1 |
|
Transmission |
PT 2116 |
| Dump |
|
Capacity - Heaped |
23 cu yd |
|
Capacity - Struck |
18 cu yd |
|
Dump Angle |
70 degrees |
|
Lower Time |
10 sec |
|
Raise Time |
22 sec |
|
Rated Payload |
31 lbs (14 kg)
|
| Electrical System |
|
Alternator |
3.396/120 |
|
Battery |
2x12 |
|
Battery Capacity |
2x170 |
|
Starter Motor |
9 |
|
Voltage |
24 V |
| Engine |
|
Displacement |
659 cu in (10,799 cu cm)
|
|
Engine Make |
Volvo |
|
Engine Model |
D11L |
|
Gross Power |
355 hp (265 kw)
|
|
Max Engine Speed |
2,000 |
|
Max Torque |
1,300 lbs ft (1,763 nm)
|
|
Net Power |
354 hp (264 kw)
|
|
Torque Measured @ |
1,200 rpm |
| General Specifications |
|
Articulated/Rigid (Since 2016)
|
Articulated |
|
Articulated/Rigid (2017)
|
Articulated |
|
Articulated/Rigid (2018)
|
Articulated |
|
Articulated/Rigid (2019)
|
Articulated |
|
Articulated/Rigid (2020)
|
Articulated |
|
Articulated/Rigid (2021)
|
Articulated |
|
Articulated/Rigid (2022)
|
Articulated |
|
Articulated/Rigid (2023)
|
Articulated |
|
Articulated/Rigid (2024)
|
Articulated |
|
Drive Configuration (Since 2016)
|
6x6 |
|
Drive Configuration (Since 2017)
|
6x4 and 6x6 |
|
Drive Configuration (2018)
|
6x4 and 6x6 |
|
Drive Configuration (2019)
|
6x4 and 6x6 |
|
Drive Configuration (2020)
|
6x4 and 6x6 |
|
Drive Configuration (2021)
|
6x4 and 6x6 |
|
Drive Configuration (2022)
|
6x4 and 6x6 |
|
Drive Configuration (2023)
|
6x4 and 6x6 |
|
Drive Configuration (2024)
|
6x4 and 6x6 |
|
Drive System Mech/Electr. (Since 2016)
|
M |
|
Drive System Mech/Electr. (2017)
|
M |
|
Drive System Mech/Electr. (2018)
|
M |
|
Drive System Mech/Electr. (2019)
|
M |
|
Drive System Mech/Electr. (2020)
|
M |
|
Drive System Mech/Electr. (2021)
|
M |
|
Drive System Mech/Electr. (2022)
|
M |
|
Drive System Mech/Electr. (2023)
|
M |
|
Drive System Mech/Electr. (2024)
|
M |
|
Engine Type (Since 2016)
|
Volvo D11L |
|
Engine Type (2017)
|
Volvo D11L |
|
Engine Type (2018)
|
Volvo D11L |
|
Engine Type (2019)
|
Volvo D11L |
|
Engine Type (Since 2020)
|
Volvo D11M |
|
Engine Type (2021)
|
Volvo D11M |
|
Engine Type (2022)
|
Volvo D11M |
|
Engine Type (2023)
|
Volvo D11M |
|
Engine Type (2024)
|
Volvo D11M |
|
Mfg. Model (Since 2018)
|
A30G |
|
Mfg. Model (2019)
|
A30G |
|
Mfg. Model (2020)
|
A30G |
|
Mfg. Model (2021)
|
A30G |
|
Mfg. Model (2022)
|
A30G |
|
Mfg. Model (2023)
|
A30G |
|
Mfg. Model (2024)
|
A30G |
|
Operating Weight (Since 2016)
|
113,759 lbs (51,600 kg)
|
|
Operating Weight (Since 2017)
|
115,302 lbs (52,300 kg)
|
|
Operating Weight (2018)
|
115,302 lbs (52,300 kg)
|
|
Operating Weight (2019)
|
115,302 lbs (52,300 kg)
|
|
Operating Weight (2020)
|
115,302 lbs (52,300 kg)
|
|
Operating Weight (2021)
|
115,302 lbs (52,300 kg)
|
|
Operating Weight (2022)
|
115,302 lbs (52,300 kg)
|
|
Operating Weight (Since 2023)
|
115,963 lbs (52,600 kg)
|
|
Operating Weight (2024)
|
115,963 lbs (52,600 kg)
|
|
Rated Payload (Since 2016)
|
31 t (31,000 kg)
|
|
Rated Payload (Since 2017)
|
33 t (33,000 kg)
|
|
Rated Payload (2018)
|
33 t (33,000 kg)
|
|
Rated Payload (2019)
|
33 t (33,000 kg)
|
|
Rated Payload (2020)
|
33 t (33,000 kg)
|
|
Rated Payload (2021)
|
33 t (33,000 kg)
|
|
Rated Payload (2022)
|
33 t (33,000 kg)
|
|
Rated Payload (Since 2023)
|
32 t (32,000 kg)
|
|
Rated Payload (2024)
|
32 t (32,000 kg)
|
| Hydraulic System |
|
Maximum System Pressure |
3,626 psi |
| Operational |
|
Fuel Capacity |
100 gal (379 l)
|
|
Tire Size |
23.5R25 |
| Transmission |
|
Max Speed |
33 mph (53 kph)
|
|
Number Of Forward Gears |
6 |
|
Number Of Reverse Gears |
2 |
|
Transmission Type |
Auto |
| Weights |
|
Total Empty |
51,368 lbs (23,300 kg)
|
|
Total Loaded |
115,302 lbs (52,300 kg)
|
