| Body |
|
Plate Thickness-Bottom |
1 in (2 cm)
|
|
Plate Thickness-Chute |
1 in (2 cm)
|
|
Plate Thickness-Front |
0 in (1 cm)
|
|
Plate Thickness-Sides |
1 in (1 cm)
|
| Capacities |
|
Brake Cooling System |
50 gal (188 l)
|
|
Cooling System |
12 gal (44 l)
|
|
Crankcase |
13 gal (50 l)
|
|
Def Tank |
10 gal (39 l)
|
|
Dropbox |
2 gal (9 l)
|
|
Fuel Tank |
127 gal (480 l)
|
|
Hydraulic Tank |
46 gal (174 l)
|
|
Transmission |
11 gal (43 l)
|
| Dimensions |
|
Dump Ground Clearance |
3 ft (1 m)
|
|
Dump Height |
24 ft (7 m)
|
|
Ground Clearance |
2 ft (1 m)
|
|
Overall Height |
12 ft (4 m)
|
|
Overall Length |
37 ft (11 m)
|
|
Overall Width |
18 ft (6 m)
|
|
Wheelbase |
10 ft (3 m)
|
| Drive Train |
|
Axles |
ARB H35 |
|
Dropbox |
IL2 ATC |
|
Torque Converter |
2.1:1 |
|
Transmission |
PT 2529 |
| Dump |
|
Capacity - Heaped |
28 cu yd |
|
Capacity - Struck |
22 cu yd |
|
Dump Angle |
72 degrees |
|
Lower Time |
10 sec |
| Electrical System |
|
Alternator |
3.396/120 |
|
Battery |
2x12 |
|
Battery Capacity |
2x170 |
|
Starter Motor |
9 |
|
Voltage |
24 V |
| Engine |
|
Displacement |
781 cu in (12,798 cu cm)
|
|
Engine Make |
Volvo |
|
Engine Model |
D13J |
|
Gross Torque |
1,741 lbs ft (2,360 nm)
|
|
Horsepower Per Sae J1349 Net |
439 hp (327 kw)
|
|
Horsepower, Gross-Sae J1995 |
441 hp (329 kw)
|
|
Max Engine Speed |
1,900 |
|
Net Torque |
1,730 lbs ft (2,345 nm)
|
| General Specifications |
|
Articulated/Rigid (Since 2016)
|
A |
|
Articulated/Rigid (2017)
|
A |
|
Articulated/Rigid (2018)
|
A |
|
Articulated/Rigid (2019)
|
A |
|
Articulated/Rigid (2020)
|
A |
|
Articulated/Rigid (2021)
|
A |
|
Articulated/Rigid (2022)
|
A |
|
Articulated/Rigid (2023)
|
A |
|
Articulated/Rigid (Since 2024)
|
Articulated |
|
Drive Configuration (Since 2016)
|
6x6 |
|
Drive Configuration (Since 2017)
|
6x4 and 6x6 |
|
Drive Configuration (2018)
|
6x4 and 6x6 |
|
Drive Configuration (2019)
|
6x4 and 6x6 |
|
Drive Configuration (2020)
|
6x4 and 6x6 |
|
Drive Configuration (2021)
|
6x4 and 6x6 |
|
Drive Configuration (2022)
|
6x4 and 6x6 |
|
Drive Configuration (2023)
|
6x4 and 6x6 |
|
Drive Configuration (2024)
|
6x4 and 6x6 |
|
Drive System Mech/Electr. (Since 2016)
|
M |
|
Drive System Mech/Electr. (2017)
|
M |
|
Drive System Mech/Electr. (2018)
|
M |
|
Drive System Mech/Electr. (2019)
|
M |
|
Drive System Mech/Electr. (2020)
|
M |
|
Drive System Mech/Electr. (2021)
|
M |
|
Drive System Mech/Electr. (2022)
|
M |
|
Drive System Mech/Electr. (2023)
|
M |
|
Drive System Mech/Electr. (2024)
|
M |
|
Engine Type (Since 2016)
|
Volvo D13J/16J |
|
Engine Type (Since 2017)
|
Volvo D13J |
|
Engine Type (2018)
|
Volvo D13J |
|
Engine Type (2019)
|
Volvo D13J |
|
Engine Type (2020)
|
Volvo D13J |
|
Engine Type (2021)
|
Volvo D13J |
|
Engine Type (2022)
|
Volvo D13J |
|
Engine Type (2023)
|
Volvo D13J |
|
Engine Type (2024)
|
Volvo D13J |
|
Mfg. Model (Since 2018)
|
A35G |
|
Mfg. Model (2019)
|
A35G |
|
Mfg. Model (2020)
|
A35G |
|
Mfg. Model (2021)
|
A35G |
|
Mfg. Model (2022)
|
A35G |
|
Mfg. Model (2023)
|
A35G |
|
Mfg. Model (2024)
|
A35G |
|
Operating Weight (Since 2016)
|
138,230 lbs (62,689 kg)
|
|
Operating Weight (Since 2017)
|
139,883 lbs (63,439 kg)
|
|
Operating Weight (2018)
|
139,883 lbs (63,439 kg)
|
|
Operating Weight (2019)
|
139,883 lbs (63,439 kg)
|
|
Operating Weight (2020)
|
139,883 lbs (63,439 kg)
|
|
Operating Weight (2021)
|
139,883 lbs (63,439 kg)
|
|
Operating Weight (2022)
|
139,883 lbs (63,439 kg)
|
|
Operating Weight (Since 2023)
|
140,655 lbs (63,789 kg)
|
|
Operating Weight (2024)
|
140,655 lbs (63,789 kg)
|
|
Rated Payload (Since 2016)
|
37 t (37,000 kg)
|
|
Rated Payload (Since 2017)
|
38 t (38,000 kg)
|
|
Rated Payload (2018)
|
38 t (38,000 kg)
|
|
Rated Payload (2019)
|
38 t (38,000 kg)
|
|
Rated Payload (2020)
|
38 t (38,000 kg)
|
|
Rated Payload (2021)
|
38 t (38,000 kg)
|
|
Rated Payload (2022)
|
38 t (38,000 kg)
|
|
Rated Payload (2023)
|
38 t (38,000 kg)
|
|
Rated Payload (2024)
|
38 t (38,000 kg)
|
| Hydraulic System |
|
Maximum System Pressure |
3,771 psi |
| Transmission |
|
Max Speed |
36 mph (57 kph)
|
|
Number Of Forward Gears |
9 |
|
Number Of Reverse Gears |
3 |
|
Transmission Type |
Auto |
| Weights |
|
Total Operating Weight |
139,883 lbs (63,439 kg)
|
