| Body |
|
Plate Thickness-Bottom |
1 in (2 cm)
|
|
Plate Thickness-Chute |
1 in (2 cm)
|
|
Plate Thickness-Front |
0 in (1 cm)
|
|
Plate Thickness-Sides |
1 in (2 cm)
|
| Capacities |
|
Brake Cooling System |
35 gal (131 l)
|
|
Cooling System |
20 gal (75 l)
|
|
Crankcase |
15 gal (55 l)
|
|
Def Tank |
16 gal (60 l)
|
|
Dropbox |
3 gal (12 l)
|
|
Fuel Tank |
198 gal (750 l)
|
|
Hydraulic Tank |
52 gal (198 l)
|
|
Transmission |
15 gal (58 l)
|
| Dimensions |
|
Dump Ground Clearance |
3 ft (1 m)
|
|
Dump Height |
26 ft (8 m)
|
|
Ground Clearance |
2 ft (1 m)
|
|
Overall Height |
13 ft (4 m)
|
|
Overall Length |
40 ft (12 m)
|
|
Overall Width |
21 ft (6 m)
|
|
Wheelbase |
11 ft (3 m)
|
| Drive Train |
|
Axles |
AHW80 |
|
Dropbox |
IL3 ATC |
|
Torque Converter |
1.85:1 |
|
Transmission |
6630 ORS |
| Dump |
|
Capacity - Heaped |
44 cu yd |
|
Capacity - Struck |
34 cu yd |
|
Dump Angle |
70 degrees |
|
Lower Time |
10 sec |
| Electrical System |
|
Alternator |
2.264/80 |
|
Battery |
2x12 |
|
Battery Capacity |
2x225 |
|
Starter Motor |
9 |
|
Voltage |
24 V |
| Engine |
|
Displacement |
982 cu in (16,092 cu cm)
|
|
Engine Make |
Volvo |
|
Engine Model |
D16J |
|
Gross Torque |
2,183 lbs ft (2,960 nm)
|
|
Horsepower Per Sae J1349 Net |
626 hp (467 kw)
|
|
Horsepower, Gross-Sae J1995 |
630 hp (470 kw)
|
|
Max Engine Speed |
1,800 rpm |
|
Net Torque |
2,170 lbs ft (2,942 nm)
|
| General Specifications |
|
Articulated/Rigid (Since 2016)
|
A |
|
Articulated/Rigid (2017)
|
A |
|
Articulated/Rigid (2018)
|
A |
|
Articulated/Rigid (2019)
|
A |
|
Articulated/Rigid (2020)
|
A |
|
Articulated/Rigid (2021)
|
A |
|
Articulated/Rigid (2022)
|
A |
|
Articulated/Rigid (2023)
|
A |
|
Articulated/Rigid (Since 2024)
|
Articulated |
|
Drive Configuration (Since 2016)
|
4x6 and 6x6 |
|
Drive Configuration (Since 2017)
|
6x4 and 6x6 |
|
Drive Configuration (2018)
|
6x4 and 6x6 |
|
Drive Configuration (2019)
|
6x4 and 6x6 |
|
Drive Configuration (2020)
|
6x4 and 6x6 |
|
Drive Configuration (2021)
|
6x4 and 6x6 |
|
Drive Configuration (2022)
|
6x4 and 6x6 |
|
Drive Configuration (2023)
|
6x4 and 6x6 |
|
Drive Configuration (2024)
|
6x4 and 6x6 |
|
Drive System Mech/Electr. (Since 2016)
|
M |
|
Drive System Mech/Electr. (2017)
|
M |
|
Drive System Mech/Electr. (2018)
|
M |
|
Drive System Mech/Electr. (2019)
|
M |
|
Drive System Mech/Electr. (2020)
|
M |
|
Drive System Mech/Electr. (2021)
|
M |
|
Drive System Mech/Electr. (2022)
|
M |
|
Drive System Mech/Electr. (2023)
|
M |
|
Drive System Mech/Electr. (2024)
|
M |
|
Engine Type (Since 2016)
|
Volvo D16J |
|
Engine Type (2017)
|
Volvo D16J |
|
Engine Type (2018)
|
Volvo D16J |
|
Engine Type (2019)
|
Volvo D16J |
|
Engine Type (2020)
|
Volvo D16J |
|
Engine Type (2021)
|
Volvo D16J |
|
Engine Type (2022)
|
Volvo D16J |
|
Engine Type (2023)
|
Volvo D16J |
|
Engine Type (2024)
|
Volvo D16J |
|
Mfg. Model (Since 2018)
|
A60H |
|
Mfg. Model (2019)
|
A60H |
|
Mfg. Model (2020)
|
A60H |
|
Mfg. Model (2021)
|
A60H |
|
Mfg. Model (2022)
|
A60H |
|
Mfg. Model (2023)
|
A60H |
|
Mfg. Model (2024)
|
A60H |
|
Operating Weight (Since 2016)
|
217,700 lbs (98,747 kg)
|
|
Operating Weight (2017)
|
217,700 lbs (98,747 kg)
|
|
Operating Weight (2018)
|
217,700 lbs (98,747 kg)
|
|
Operating Weight (2019)
|
217,700 lbs (98,747 kg)
|
|
Operating Weight (2020)
|
217,700 lbs (98,747 kg)
|
|
Operating Weight (2021)
|
217,700 lbs (98,747 kg)
|
|
Operating Weight (2022)
|
217,700 lbs (98,747 kg)
|
|
Operating Weight (2023)
|
217,700 lbs (98,747 kg)
|
|
Operating Weight (2024)
|
217,700 lbs (98,747 kg)
|
|
Rated Payload (Since 2016)
|
61 t (60,600 kg)
|
|
Rated Payload (2017)
|
61 t (60,600 kg)
|
|
Rated Payload (2018)
|
61 t (60,600 kg)
|
|
Rated Payload (2019)
|
61 t (60,600 kg)
|
|
Rated Payload (2020)
|
61 t (60,600 kg)
|
|
Rated Payload (2021)
|
61 t (60,600 kg)
|
|
Rated Payload (2022)
|
61 t (60,600 kg)
|
|
Rated Payload (2023)
|
61 t (60,600 kg)
|
|
Rated Payload (2024)
|
61 t (60,600 kg)
|
| Hydraulic System |
|
Maximum System Pressure |
4,061 psi |
| Transmission |
|
Max Speed |
34 mph (55 kph)
|
|
Number Of Forward Gears |
6 |
|
Number Of Reverse Gears |
2 |
|
Transmission Type |
Auto |
| Weights |
|
Total Operating Weight |
217,707 lbs (98,750 kg)
|
