| Bucket |
|
Breakout Force, Curl |
4,013 lbs (1,820 kg)
|
|
Breakout Force, Lift |
3,902 lbs (1,770 kg)
|
|
General Purpose Bucket Heaped Cap |
1 cu yd |
|
General Purpose Bucket Height |
2 ft (1 m)
|
|
General Purpose Bucket Length |
3 ft (1 m)
|
|
General Purpose Bucket Weight |
322 lbs (146 kg)
|
|
General Purpose Bucket Width |
5 ft (2 m)
|
|
Landscape Bucket Heaped Cap |
1 cu yd |
|
Landscape Bucket Height |
2 ft (1 m)
|
|
Landscape Bucket Length |
3 ft (1 m)
|
|
Landscape Bucket Weight |
0.3 in2 |
|
Landscape Bucket Width |
5 ft (2 m)
|
|
Multi Purpose Bucket Heaped Cap |
1 cu yd |
|
Multi Purpose Bucket Height |
2 ft (1 m)
|
|
Multi Purpose Bucket Length |
3 ft (1 m)
|
|
Multi Purpose Bucket Weight |
571 lbs (259 kg)
|
|
Multi Purpose Bucket Width |
6 ft (2 m)
|
| Capacities |
|
Cooling System |
3 gal (10 l)
|
|
Engine Oil W/ Filter Change |
3 gal (10 l)
|
|
Fuel Tank |
26 gal (98 l)
|
|
Hydraulic Oil Reservoir |
26 gal (98 l)
|
|
Hydraulic System |
44 gal (165 l)
|
| Dimensions |
|
Angle Of Departure |
25 degrees |
|
Attachment Roll Back Angle |
30 degrees |
|
Dump Angle |
42 degrees |
|
Dump Height |
0 ft (0 m)
|
|
Dump Reach |
22 in (56 cm)
|
|
Ground Clearance |
8 in (21 cm)
|
|
Height |
7 ft (2 m)
|
|
Height To Hinge Pin |
5 in (12 cm)
|
|
Length |
12 ft (4 m)
|
|
Overall Height |
7 ft (2 m)
|
|
Overall Length (L/Bucket) |
9 ft (3 m)
|
|
Overall Length (W/Bucket) |
11 ft (3 m)
|
|
Turning Radius |
5 ft (2 m)
|
|
Turning Radius Front L/Bucket |
3 ft (1 m)
|
|
Turning Radius Front W/Bucket |
7 ft (2 m)
|
|
Weight |
6,355 lbs (2,883 kg)
|
|
Wheelbase |
4 ft (1 m)
|
|
Width |
5 ft (2 m)
|
| Engine |
|
Alternator |
360000 amps |
|
Aspiration |
Turbo |
|
Battery |
12 - 109 (V - Ah) |
|
Displacement |
114 cu in (1,860 cu cm)
|
|
Engine Model |
KDI 1903 TCR |
|
Fuel Type |
Diesel |
|
Gross Horsepower – Sae J1995 |
42 hp (31 kw)
|
|
Max Torque |
166 lbs ft (225 nm)
|
|
Net Power |
42 hp (31 kw)
|
|
Number Of Cylinders |
3 |
|
Starter |
3 hp (2 kw)
|
| General Specifications |
|
ENGINE POWER (Since 2016)
|
56 hp (42 kw)
|
|
ENGINE POWER (2017)
|
56 hp (42 kw)
|
|
ENGINE POWER (2019)
|
56 hp (42 kw)
|
|
ENGINE POWER (2020)
|
56 hp (42 kw)
|
|
MODEL (Since 2016)
|
MC70C |
|
MODEL (2017)
|
MC70C |
|
MODEL (2019)
|
MC70C |
|
MODEL (2020)
|
MC70C |
|
OPERATING LOAD (Since 2016)
|
1,550 lbs (703 kg)
|
|
OPERATING LOAD (2017)
|
1,550 lbs (703 kg)
|
|
OPERATING WIDTH (Since 2016)
|
63 in (160 cm)
|
|
OPERATING WIDTH (2017)
|
63 in (160 cm)
|
|
OPERATING WIDTH (2019)
|
63 in (160 cm)
|
|
OPERATING WIDTH (2020)
|
63 in (160 cm)
|
|
RATED OPERATING CAPACITY (50%) (Since 2019)
|
1,550 lbs (703 kg)
|
|
RATED OPERATING CAPACITY (50%) (2020)
|
1,550 lbs (703 kg)
|
| Loader |
|
Bucket Width |
66 in (168 cm)
|
|
High Flow Pump Output |
27 gpm (100 lpm)
|
|
Standard Hydraulic Pump Output |
19 gpm (70 lpm)
|
|
System Pressure |
230 psi |
| Performance |
|
Curl |
1 sec |
|
Dump |
2 sec |
|
Lift Arm Path |
Radial |
|
Lower (Power Down) |
1 sec |
|
Raise (Lifting) |
3 sec |
|
Rated Operating Capacity (Iso 14397) |
3,100 lbs (1,406 kg)
|
| Speeds |
|
Single Speed |
12 mph (19 kph)
|
| Weights |
|
Weight |
6,356 lbs (2,883 kg)
|
