| Axles |
|
Axle oil front |
10 gal (36 l)
|
|
Axle oil rear |
11 gal (41 l)
|
|
Front |
Volvo AWB 31 |
|
Rear |
Volvo AWB 30 |
|
Rear axle oscillation |
13 degrees |
| Bucket |
|
Breakout Force |
40,893 lbs (18,545 kg)
|
| Dimensions |
|
Ground Clearance |
2 ft (0 m)
|
|
Height - Top of Cab |
11 ft (3 m)
|
|
Hinge Pin - Max Height |
13 ft (4 m)
|
|
Length with Bucket on Ground |
27 ft (8 m)
|
|
Wheelbase |
2 ft (0 m)
|
|
Width Over Tires |
9 ft (3 m)
|
| Drive System |
|
Torque multiplication, stall ratio |
2.47:1 |
|
Transmission |
Volvo HTL 206C |
|
Transport speed, maximum |
25 mph (40 kph)
|
| Electrical System |
|
Alternator rating |
2280/80 (W/A) |
|
Battery capacity |
2 x 170 Ah |
|
Cold cranking capacity |
1000 A |
|
Starter motor output |
7 hp (6 kw)
|
|
Voltage |
24 V |
| Engine |
|
Aspiration |
Turbocharged |
|
Displacement |
476 cu in (7,800 cu cm)
|
|
Engine Model |
Volvo D8J |
|
Gross Power |
256 hp (191 kw)
|
|
Number of Cylinders |
6 |
|
Power Measured @ |
1,800 rpm |
|
Torque Measured @ |
1,450 rpm |
| General Specifications |
|
Bucket Capacity (Since 2016)
|
3.2 - 12.4 (2.4 - 9.5) |
|
Bucket Capacity (Since 2017)
|
3.5 - 12.4 (2.7 - 9.5) |
|
Bucket Capacity (Since 2019)
|
3.25 - 12.5 (2.5 - 9.5) |
|
Bucket Capacity (Since 2020)
|
7.8 (6) |
|
Bucket Capacity (2021)
|
7.8 (6) |
|
Bucket Capacity (Since 2022)
|
4.6 (3.5) |
|
Bucket Capacity (2023)
|
4.6 (3.5) |
|
Bucket Capacity (2024)
|
4.6 (3.5) |
|
Engine Power (Since 2016)
|
258 192) |
|
Engine Power (Since 2017)
|
254 (189) |
|
Engine Power (Since 2019)
|
256 (191) |
|
Engine Power (Since 2020)
|
254 (189) |
|
Engine Power (2021)
|
254 (189) |
|
Engine Power (Since 2022)
|
256 (191) |
|
Engine Power (2023)
|
256 (191) |
|
Engine Power (2024)
|
256 (191) |
|
Engine type (Since 2016)
|
D8J |
|
Engine type (2017)
|
D8J |
|
Engine type (Since 2019)
|
Volvo D8J |
|
Engine type (2020)
|
Volvo D8J |
|
Engine type (2021)
|
Volvo D8J |
|
Engine type (2022)
|
Volvo D8J |
|
Engine type (2023)
|
Volvo D8J |
|
Engine type (Since 2024)
|
Volvo D8M |
|
Max Dump Height (Since 2016)
|
9.2 (2.8) |
|
Max Dump Height (2017)
|
9.2 (2.8) |
|
Max Dump Height (Since 2019)
|
9.5 (2.8) |
|
Max Dump Height (Since 2020)
|
9.3 (2.8) |
|
Max Dump Height (2021)
|
9.3 (2.8) |
|
Max Dump Height (Since 2022)
|
9 (2.7) |
|
Max Dump Height (2023)
|
9 (2.7) |
|
Max Dump Height (2024)
|
9 (2.7) |
|
Operating Weight (Since 2016)
|
40,920 (18,561) |
|
Operating Weight (2017)
|
40,920 (18,561) |
|
Operating Weight (Since 2019)
|
39,680 - 45,635 (17,999 - 20,700) |
|
Operating Weight (Since 2020)
|
40,920 (18,561) |
|
Operating Weight (2021)
|
40,920 (18,561) |
|
Operating Weight (Since 2022)
|
43,030 (19,510) |
|
Operating Weight (2023)
|
43,030 (19,510) |
|
Operating Weight (2024)
|
43,030 (19,510) |
| Hydraulic cycle times (unloaded) |
|
Lift |
5 seconds |
|
Lower |
3 seconds |
|
Tilt |
2 seconds |
|
Total cycle time |
10 seconds |
| Hydraulic System |
|
Engine speed |
1,900 rpm |
|
Working pressure |
Pump 1 - 27 MPa Pump 2 - 29 MPa Pump 3 - 21 MPa |
| Operating Specifications |
|
Cooling System Fluid Capacity |
11 gal (43 l)
|
|
DEF tank capacity |
7 gal (25 l)
|
|
Engine Oil Fluid Capacity |
6 gal (22 l)
|
|
Fuel Capacity |
71 gal (270 l)
|
|
Hydraulic System Fluid Capacity |
35 gal (133 l)
|
|
Transmission Fluid Capacity |
10 gal (38 l)
|
| Steering System |
|
Articulation angle |
40 degrees |
|
Cylinder bore |
3 in (8 cm)
|
|
Maximum flow |
32 gpm (120 lpm)
|
|
Rod diameter |
2 in (5 cm)
|
|
Steering cylinders |
2 |
|
Stroke |
2 ft (0 m)
|
|
Working pressure |
21 MPa 210 bar |
| Weights |
|
Operational Weight |
40,920 lbs (18,558 kg)
|
