| Axles |
|
Axle Oil Front |
20 gal (77 l)
|
|
Axle Oil Rear |
19 gal (71 l)
|
|
Front |
Volvo AWB 50 |
|
Rear |
Volvo AWB 41 |
|
Rear Axle Oscillation |
15 degrees |
| Bucket |
|
Breakout Force |
54,134 lbs (24,555 kg)
|
| Capacities |
|
Fuel Tank (Since 2026)
|
97 gal (US) |
|
Heaped Capacity (Since 2026)
|
8 yd³ |
|
Hydraulic Tank (Since 2026)
|
60 gal (US) |
| Dimensions |
|
Articulated Steering Angle (Since 2026)
|
37 |
|
Dump Angle - Maximum (Since 2026)
|
48 |
|
Full Lift Dump Height (Since 2026)
|
10ft 1in ft/in |
|
Ground Clearance |
2 ft (1 m)
|
|
Ground Clearance (Since 2026)
|
20 in (51 cm)
|
|
Height |
12 ft (4 m)
|
|
Height - Over Cab (Since 2026)
|
12ft 2in ft/in |
|
Height To Top Of Cab |
12 ft (4 m)
|
|
Hinge Pin - Max Height |
15 ft (5 m)
|
|
Length |
31 ft (10 m)
|
|
Length With Bucket On Ground |
31 ft (9 m)
|
|
Length With Bucket On Ground (Since 2026)
|
30ft 10in ft/in |
|
Loader - Geometry (Since 2026)
|
Torque Parallel |
|
Reach At Max Lift And Dump |
5 ft (2 m)
|
|
Weight |
72,000 lbs (32,659 kg)
|
|
Wheelbase |
12 ft (4 m)
|
|
Wheelbase (Since 2026)
|
12ft 2in ft/in |
|
Width |
10 ft (3 m)
|
|
Width Over Tires |
10 ft (3 m)
|
| Drive Train |
|
Torque Multiplication, Stall Ratio |
2.02:1 |
|
Transmission |
Volvo HTL 310 |
|
Transport Speed, Maximum |
23 mph (37 kph)
|
| Driveline |
|
After Treatment System (Since 2026)
|
Diesel Particulate Filter |
|
Aspiration (Since 2026)
|
Var. Geometry Turbo - Charge Air Cooled |
|
Displacement (Since 2026)
|
781 in³ |
|
Emissions Technology (Since 2026)
|
Cooled Exhaust Gas Recirculation |
|
Engine Manufacturer (Since 2026)
|
Volvo |
|
Engine Model (Since 2026)
|
D13J |
|
Engine Output - Net (Since 2026)
|
375 hp (280 kw)
|
|
Front Axle - Type (Since 2026)
|
Planetary |
|
Number Of Cylinders (Since 2026)
|
6 |
|
Rated Speed (Since 2026)
|
1,300 |
|
Rear Axle - Type (Since 2026)
|
Planetary |
|
Service Brake - Actuation (Since 2026)
|
Hydraulic |
|
Service Brake - Type (Since 2026)
|
Wet Disc |
|
Speed - Forward Maximum (Since 2026)
|
23 mph (37 kph)
|
|
Steering - Type (Since 2026)
|
Articulation |
|
Tire Size (Since 2026)
|
29.5 R25 |
|
Transmission Type (Since 2026)
|
Powershift |
| Electrical System |
|
Alternator Rating |
2280/80 (W/A) |
|
Batteries |
2 x 12 V |
|
Battery Capacity |
2 x 170 Ah |
|
Cold Cranking Capacity |
1000 A |
|
Starter Motor Output |
9 hp (7 kw)
|
|
Voltage |
24 V V |
| Engine |
|
Aspiration |
Turbocharged |
|
Displacement |
781 cu in (12,802 cu cm)
|
|
Engine Model |
Volvo D13J |
|
Gross Power |
368 hp (274 kw)
|
|
Max Torque |
Gross - 2231 Nm, Net - 2220 Nm |
|
Net Power |
366 hp (273 kw)
|
|
Number Of Cylinders |
6 |
|
Power Measured @ |
1,400 rpm |
|
Torque Measured @ |
1,100 rpm |
| General Specifications |
|
Bucket Capacity (Since 2016)
|
3.5 - 12.4 (2.7 - 9.5) |
|
Bucket Capacity (Since 2017)
|
5.9 - 20.9 (4.5 - 15.9) |
|
Bucket Capacity (2019)
|
5.9 - 20.9 (4.5 - 15.9) |
|
Bucket Capacity (Since 2020)
|
13 cu yd |
|
Bucket Capacity (2021)
|
13 cu yd |
|
Bucket Capacity (Since 2022)
|
8 cu yd |
|
Bucket Capacity (2023)
|
8 cu yd |
|
Bucket Capacity (2024)
|
8 cu yd |
|
Engine Power (Since 2016)
|
371 hp (277 kw)
|
|
Engine Power (Since 2017)
|
366 hp (273 kw)
|
|
Engine Power (2019)
|
366 hp (273 kw)
|
|
Engine Power (2020)
|
366 hp (273 kw)
|
|
Engine Power (2021)
|
366 hp (273 kw)
|
|
Engine Power (2022)
|
366 hp (273 kw)
|
|
Engine Power (2023)
|
366 hp (273 kw)
|
|
Engine Power (2024)
|
366 hp (273 kw)
|
|
Engine type (Since 2016)
|
D13J |
|
Engine type (2017)
|
D13J |
|
Engine type (Since 2019)
|
Volvo D13J |
|
Engine type (Since 2020)
|
Volvo D13J (Tier 4F) |
|
Engine type (2021)
|
Volvo D13J (Tier 4F) |
|
Engine type (2022)
|
Volvo D13J (Tier 4F) |
|
Engine type (2023)
|
Volvo D13J (Tier 4F) |
|
Engine type (2024)
|
Volvo D13J (Tier 4F) |
|
Max Dump Height (Since 2016)
|
10 ft (3 m)
|
|
Max Dump Height (2017)
|
10 ft (3 m)
|
|
Max Dump Height (2019)
|
10 ft (3 m)
|
|
Max Dump Height (Since 2020)
|
10 ft (3 m)
|
|
Max Dump Height (2021)
|
10 ft (3 m)
|
|
Max Dump Height (2022)
|
10 ft (3 m)
|
|
Max Dump Height (2023)
|
10 ft (3 m)
|
|
Max Dump Height (2024)
|
10 ft (3 m)
|
|
Operating Weight (Since 2016)
|
70,440 lbs (31,951 kg)
|
|
Operating Weight (2017)
|
70,440 lbs (31,951 kg)
|
|
Operating Weight (Since 2019)
|
68,780 - 72,970 (31,198 - 33,099) |
|
Operating Weight (Since 2020)
|
73,190 lbs (33,198 kg)
|
|
Operating Weight (2021)
|
73,190 lbs (33,198 kg)
|
|
Operating Weight (Since 2022)
|
71,140 lbs (32,269 kg)
|
|
Operating Weight (2023)
|
71,140 lbs (32,269 kg)
|
|
Operating Weight (2024)
|
71,140 lbs (32,269 kg)
|
| Hydraulic Cycle Times (Unloaded) |
|
Lift |
7 sec |
|
Lower |
3 sec |
|
Tilt |
2 sec |
|
Total Cycle Time |
12 sec |
| Hydraulic System |
|
Engine Speed |
1,900 rpm |
|
Working Pressure |
Pump 1 - 29 MPa, Pump 2 - 31 MPa, Pump 3 - 25 MPa |
| Operational |
|
Cooling System Fluid Capacity |
15 gal (55 l)
|
|
Def Tank Capacity |
8 gal (31 l)
|
|
Engine Oil Fluid Capacity |
13 gal (50 l)
|
|
Fuel Capacity |
97 gal (366 l)
|
|
Hydraulic System Fluid Capacity |
60 gal (226 l)
|
|
Operating Weight |
70,967 lbs (32,190 kg)
|
|
Transmission Fluid Capacity |
13 gal (48 l)
|
| Performance |
|
Cumulative Pump Flow (Since 2026)
|
120 gal (US)/min |
|
Full Turn Tipping Load (Since 2026)
|
47,650 lb |
|
Number Of Pumps - Main (Since 2026)
|
2 |
| Steering System |
|
Articulation Angle |
37 degrees |
|
Cylinder Bore |
4 in (10 cm)
|
|
Maximum Flow |
53 gpm (202 lpm)
|
|
Rod Diameter |
2 in (6 cm)
|
|
Steering Cylinders |
2 |
|
Stroke |
2 ft (1 m)
|
|
Working Pressure |
21 MPa, 210 bar |
| Weights |
|
Operating Weight (Since 2026)
|
71,020 lb |
