| Approximate Weights - Dual Slope |
|
Body |
34,785 lbs (15,778 kg)
|
|
Chassis |
106,964 lbs (48,518 kg)
|
| Approximate Weights - Flat Floor |
|
Body |
1,300 lbs (590 kg)
|
| Body Hoists |
|
Body Lower Time - Float |
13 seconds |
|
Body Raise Time - High Idle |
15 seconds |
|
Pump Flow - High Idle |
119 gpm (450 lpm)
|
|
Relief Valve Setting - Raise |
2,750 psi |
| Brakes |
|
Brake Surface - Rear |
15,828 cu in (259,375 cu cm)
|
|
Standards |
2.74:1 |
| Capacity - Dual Slope - 100% Fill Factor |
|
Heaped 2:1 (SAE) |
79 cu yd (60 cu m)
|
| Capacity - Flat Floor - 100% Fill Factor |
|
Heaped 2:1 (SAE) |
SAE J1040 MAY94 ISO 3471:1997 cu yd |
| Dimensions |
|
Centerline Front Tire Width |
14 ft (4 m)
|
|
Dump Ground Clearance |
3 ft (1 m)
|
|
Dump Height |
33 ft (10 m)
|
|
Front Canopy Height |
17 ft (5 m)
|
|
Ground Clearance |
3 ft (1 m)
|
|
Inside Body Length |
24 ft (7 m)
|
|
Loading Height - Empty |
14 ft (4 m)
|
|
Operating Width |
20 ft (6 m)
|
|
Overall Height |
17 ft (5 m)
|
|
Overall Height - Body Raised |
33 ft (10 m)
|
|
Overall Length |
32 ft (10 m)
|
|
Overall Width |
20 ft (6 m)
|
|
Wheel Base |
15 ft (5 m)
|
|
Wheelbase |
15 ft (5 m)
|
| Dump |
|
Dump Angle |
1,750 |
|
Load Capacity - heaped |
79 cu yd (61 cu m)
|
|
Load Capacity - Struck |
55 cu yd (42 cu m)
|
|
Raise Time |
15 seconds |
|
Rated Payload |
200,000 lbs (90,719 kg)
|
| Engine |
|
Bore |
7 in (17 cm)
|
|
Displacement |
2,105 cu in (34,495 cu cm)
|
|
Engine Model |
Cat 3508B EUI |
|
Flywheel Power |
938 hp (699 kw)
|
|
Gross Power |
1,000 hp (746 kw)
|
|
Gross Power - SAE J1995 |
1,000 hp (746 kw)
|
|
Max Torque |
3,476 lbs ft (4,713 nm)
|
|
Net Power |
938 hp (699 kw)
|
|
Net Power - 80/1269/EEC |
938 hp (699 kw)
|
|
Net Power - Cat |
938 hp (699 kw)
|
|
Net Power - ISO 9249 |
938 hp (699 kw)
|
|
Net Power - SAE J1349 |
938 hp (699 kw)
|
|
Number of Cylinders |
8 |
|
Stroke |
8 in (19 cm)
|
|
Torque Measured @ |
1,300 rpm |
| Final Drives |
|
Planetary Ratio |
7.00:1 |
|
Total Reduction Ratio |
19.16:1 |
| Operating Specifications |
|
Alternator Supplied Amperage |
automatic power shift |
|
Body Capacity - SAE 2:1 |
79 cu yd (60 cu m)
|
|
Body Capacity - Struck |
55 cu yd (42 cu m)
|
|
Brake/Hoist System Fluid Capacity |
110 gal (415 l)
|
|
Circle Clearance Diameter |
86 ft (26 m)
|
|
Cooling System Fluid Capacity |
86 gal (325 l)
|
|
Diff and Final Drive Fluid Capacity |
87 gal (329 l)
|
|
Engine Oil Capacity |
33 gal (124 l)
|
|
Fuel Capacity |
300 gal (1,137 l)
|
|
Lower Time |
14 seconds |
|
Maximum Capacity |
178,920 lbs (81,157 kg)
|
|
Nominal Payload Capacity |
87 lbs (39 kg)
|
|
Nominal Payload Class (100%) |
178,920 lbs (81,157 kg)
|
|
Raise Time |
15 seconds |
|
Steer Angle |
32 degrees |
|
Steering System Fluid Capacity |
22 gal (84 l)
|
|
Top Speed - Loaded |
40 mph (64 kph)
|
| ROPS |
|
ROPS Standards |
ANSI/SAE J1166 MAY90 SAE J88 JUN96 |
| Service Refill Capacities |
|
Brake Hoist System - Includes Tank |
110 gal (415 l)
|
|
Brake/Hoist Hydraulic Tank |
200,000 gal (757,000 l)
|
|
Cooling System |
86 gal (326 l)
|
|
Differential - Final Drives |
87 gal (329 l)
|
|
Fuel Tank |
300 gal (1,136 l)
|
|
Steering System - Including Tank |
22 gal (83 l)
|
|
Steering Tank |
15 gal (57 l)
|
|
Torque Converter - Brake - Hoist Hydraulic Tank |
66 gal (250 l)
|
|
Torque Converter - Transmission Sump |
107,100 gal (405,374 l)
|
|
Torque Converter - Transmission System - Including Sump |
37 gal (138 l)
|
| Sound |
|
Sound Standards |
ANSI/SAE J1166 MAY90 SAE J88 JUN96 |
| Steering System |
|
Steer Angle |
32 degrees |
|
Steering Standards |
SAE J1511 OCT90 ISO 5010:1992 (E) |
|
Turning Circle - Clearance Diameter |
ISO 3450: 1996; SAE J1473 OCT90 ft |
| Tires |
|
Standard Tire |
27.00-R49 (E4) |
|
Standard Tires |
432 |
| Transmission |
|
Forward - 1 |
7 mph (10 kph)
|
|
Forward - 2 |
9 mph (14 kph)
|
|
Forward - 3 |
12 mph (19 kph)
|
|
Forward - 4 |
16 mph (26 kph)
|
|
Forward - 5 |
22 mph (35 kph)
|
|
Forward - 6 |
29 mph (47 kph)
|
|
Forward - 7 |
40 mph (64 kph)
|
|
Max Speed |
38 mph (61 kph)
|
|
Number of Gears - Forward |
7 |
|
Number of Gears - Reverse |
1 |
|
Reverse |
7 mph (12 kph)
|
| Weights |
|
Chassis Weight |
107,100 lbs (48,580 kg)
|
|
Empty Weight |
155,000 lbs (70,307 kg)
|
|
Front Axle - Empty |
47% |
|
Front Axle - Loaded |
33% |
|
Loaded Weight |
355,011 lbs (161,030 kg)
|
|
Rear Axle - Empty |
53% |
|
Rear Axle - Loaded |
67% |
|
Weight Distribution Front - empty |
45.4% |
|
Weight Distribution Front - loaded |
33.3% |
|
Weight Distribution Rear - empty |
54.6% |
|
Weight Distribution Rear - loaded |
66.7% |
