| Backhoe |
|
Dig Depth |
8 ft (3 m)
|
|
Loading Height |
8 ft (2 m)
|
|
Max dig depth |
8 ft (3 m)
|
|
Max Digging Depth |
8 ft (3 m)
|
|
Reach From Swivel |
11 ft (3 m)
|
| Capacities |
|
Cooling system |
2 gal (8 l)
|
|
Engine oil with filter |
3 gal (10 l)
|
|
Fuel Tank |
12 gal (45 l)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height to Top of Suspended Cab |
7 ft (2 m)
|
|
Transport Length |
11 ft (3 m)
|
|
Transport Width |
5 ft (1 m)
|
|
Wheelbase |
4 ft (1 m)
|
| Electrical System |
|
Alternator |
50 |
|
Battery |
72A/hour |
|
Front working lights |
2 adjustable |
|
Gauges |
Fuel Level Hour meter |
|
Pre-wire |
Beacon |
|
Rear working lights |
2 adjustable |
| Engine |
|
Aspiration |
Natural |
|
Displacement |
134 cu in (2,201 cu cm)
|
|
Emissions Certification |
Stage EC Stage IIIA |
|
Engine Model |
104-22 |
|
Fuel Type |
Replaceable cartridge plus water/sediment separator prefilter |
|
Gross Power |
50 hp (37 kw)
|
|
Net Max Torque |
100 lbs ft (135 nm)
|
|
Net Power |
47 hp (35 kw)
|
|
Number of Cylinders |
4 |
|
Power Measured @ |
2,800 rpm |
|
Rated engine speed |
2,800 rpm |
|
Torque Measured @ |
2,000 rpm |
| General Specifications |
|
4th Gear Fwd mph (kmh) (Since 2007)
|
hydrostatic |
|
4th Gear Fwd mph (kmh) (2008)
|
hydrostatic |
|
4TH GEAR FWD MPH (KMH) (Since 2010)
|
hydrostatic |
|
BACKHOE LOADING HEIGHT FT. (M) (Since 2009)
|
6.83 (2) |
|
Backhoe Loading Height ft. (m) (Since 2011)
|
8.2 (2.5) |
|
Backhoe Loading Height ft. (m) (2012)
|
8.2 (2.5) |
|
Backhoe Loading Height ft. (m) (2013)
|
8.2 (2.5) |
|
Breakout Force lbs (kgs) (Since 2007)
|
5,179 (2,350) |
|
Breakout Force lbs (kgs) (2008)
|
5,179 (2,350) |
|
BREAKOUT FORCE LBS. (KG) (Since 2010)
|
5,179 (2,350) |
|
Digging Depth ft (m) (Since 2007)
|
8.33 (2.54) |
|
Digging Depth ft (m) (Since 2008)
|
8.33 (2.5) |
|
DIGGING DEPTH FT. (M) (Since 2010)
|
8.33 (2.5) |
|
Lift Capacity lbs (kgs) (Since 2007)
|
1,345 (610) |
|
Lift Capacity lbs (kgs) (2008)
|
1,345 (610) |
|
LIFT CAPACITY LBS. (KG) (Since 2010)
|
1,345 (610) |
|
LOADER BREAKOUT FORCE LBS. (KG) (Since 2009)
|
5,179 (2,350) |
|
Loader Breakout Force lbs. (kg) (Since 2011)
|
5,179 (2,350) |
|
Loader Breakout Force lbs. (kg) (2012)
|
5,179 (2,350) |
|
Loader Breakout Force lbs. (kg) (2013)
|
5,179 (2,350) |
|
LOADER LIFT CAPACITY LBS. (KG) (Since 2009)
|
1,345 (610) |
|
Loader Lift Capacity lbs. (kg) (Since 2011)
|
1,345 (610) |
|
Loader Lift Capacity lbs. (kg) (2012)
|
1,345 (610) |
|
Loader Lift Capacity lbs. (kg) (2013)
|
1,345 (610) |
|
LOADER SAE HP (KW) (Since 2009)
|
50 (37) |
|
Loader SAE HP (kw) (Since 2011)
|
50 (37) |
|
Loader SAE HP (kw) (2012)
|
50 (37) |
|
Loader SAE HP (kw) (2013)
|
50 (37) |
|
Loading Height ft (m) (Since 2007)
|
7.66 (2.35) |
|
Loading Height ft (m) (Since 2008)
|
7.66 (2.4) |
|
LOADING HEIGHT FT. (M) (Since 2010)
|
6.83 (2) |
|
MAX DIGGING DEPTH FT. (M) (Since 2009)
|
8.33 (2.5) |
|
Max Digging Depth ft. (m) (Since 2011)
|
8.3 (2.5) |
|
Max Digging Depth ft. (m) (2012)
|
8.3 (2.5) |
|
Max Digging Depth ft. (m) (Since 2013)
|
8.3 (2.55) |
|
Operating Weight lbs (kg) (Since 2007)
|
6,150 (2,790) |
|
Operating Weight lbs (kg) (2008)
|
6,150 (2,790) |
|
OPERATING WEIGHT LBS. (KG) (Since 2009)
|
6,159 (2,790) |
|
Operating Weight lbs. (kg) (Since 2011)
|
6,150 (2,790) |
|
Operating Weight lbs. (kg) (2012)
|
6,150 (2,790) |
|
Operating Weight lbs. (kg) (2013)
|
6,150 (2,790) |
|
SAE HP (KW) (Since 2010)
|
50 (37) |
|
SAE Net hp (kw) (Since 2007)
|
47 (35) |
|
SAE Net hp (kw) (2008)
|
47 (35) |
|
TRAVEL SPEED 4TH GEAR FWD MPH (KMH) (Since 2009)
|
hydrostatic |
|
Travel Speed 4th Gear Fwd MPH (kmh) (Since 2011)
|
7.0 (11.3) |
|
Travel Speed 4th Gear Fwd MPH (kmh) (2012)
|
7.0 (11.3) |
|
Travel Speed 4th Gear Fwd MPH (kmh) (Since 2013)
|
7 (11.3) |
|
WEIGHT LBS. (KG) (Since 2010)
|
6,159 (2,790) |
| Hydraulic System |
|
Pump Flow Capacity |
12 gpm (45 lpm)
|
|
Relief Valve Pressure |
3,000 psi |
| Loader |
|
Breakout Force |
5,179 lbs (2,349 kg)
|
|
Bucket Breakout Force |
5,179 lbs (2,349 kg)
|
|
Bucket Width |
56 in (143 cm)
|
|
Clearance at Max Dump Height |
7 ft (2 m)
|
|
Dig Depth |
2 in (5 cm)
|
|
Dump height |
7 ft (2 m)
|
|
Lift Capacity |
1,345 lbs (610 kg)
|
|
Lift Capacity |
1,345 lbs (610 kg)
|
|
Load over height |
8 ft (3 m)
|
|
Reach at Max Dump Height |
1 ft (0 m)
|
|
SAE - Net |
47 hp (35 kw)
|
| Operating Specifications |
|
Cooling System Fluid Capacity |
2 gal (8 l)
|
|
Fuel Capacity |
12 gal (45 l)
|
|
Hydraulic System Fluid Capacity |
12 gal (45 l)
|
|
Oil System Fluid Capacity |
1 gal (5 l)
|
|
Operating Voltage |
12 volts |
|
Operating Weight |
6,150 lbs (2,790 kg)
|
|
Operating Weight 4wd |
6,150 lbs (2,790 kg)
|
|
Tire Size Front - 2wd / 4wd |
7x15 |
| Tires |
|
Rear Tires Size |
7x15 |
| Transmission |
|
Max Speed |
7 mph (11 kph)
|
|
Max Speed - Reverse |
7 mph (11 kph)
|
|
Number of Forward Gears |
1 |
|
Number of Reverse Gears |
1 |
|
Transmission Type |
Hydrostatic |
| Travel Speed |
|
4Th Gear Fwd |
7 mph (11 kph)
|
