For Sale: Call for Price
Machine Location: | YOUNGSTOWN, OH |
More Information: | https://valleyindustrialtrucks.com/inventory/aerial+work+platforms/2013-jlg-2646es-akron-oh-647d25be188726160e07e622/ |
Supplied by HeavyEquipmentData.com →
Brakes | |
Brakes Type | Electric, Friction |
Dimensions | |
Ground Clearance | 5.0 in ( 13 cm ) |
Height w/ Rails | 78.0 ft ( 24 m ) |
Height w/o Rails | 6.5 ft ( 2 m ) |
Overall Length | 100.0 in ( 254 cm ) |
Overall Width | 3.9 ft ( 1 m ) |
Platform Dimension A | 8.3 ft ( 3 m ) |
Platform Dimension B | 3.8 ft ( 1 m ) |
Turning Radius | 7.2 ft ( 2 m ) |
Wheelbase | 6.1 ft ( 2 m ) |
Engine | |
Battery Amp Hours | 200.0 |
Charger Amps | 20 |
Maximum Ground Bearing Pressure | 87.0 psi |
Number of Batteries | 4.0 |
System Voltage | 24 V |
Performance | |
Drive Speed - Platform Elevated | 0.5 mph ( 1 kph ) |
Drive Speed - Platform Lowered | 2.5 mph ( 4 kph ) |
Gradeability | 25% |
Hydraulic Pump Type | Fixed Displacement Gear |
Hydraulic System Fluid Capacity | 1.7 gal ( 6 l ) |
Max Speed | 2.5 mph ( 4 kph ) |
Maximum Drive Height | 26.0 ft ( 8 m ) |
Maximum Lift Height | 26.0 ft ( 8 m ) |
Operating Weight | 4,768.6 lbs ( 2,163 kg ) |
Tire Fill/Type | Solid, Non-marking |
Tire Size | 16x5 in |
Platform | |
Deck Extension | 35.5 in ( 90 cm ) |
Height of Rails | 3.7 ft ( 1 m ) |
Lift Time | 41.0 seconds |
Lower Time | 50.0 seconds |
Max Platform Height | 26.0 ft ( 8 m ) |
Max Platform Weight Capacity | 1,000.9 lbs ( 454 kg ) |
Max Working Height | 32.0 ft ( 10 m ) |
Platform Capacity - Extension | 250.0 lbs ( 113 kg ) |
Platform Capacity - Unrestricted | 1,000.0 lbs ( 454 kg ) |
Platform Inner Length | 98.5 in ( 250 cm ) |
Platform Inner Width | 44.1 in ( 112 cm ) |
Platform Railing Height | 26.0 ft ( 8 m ) |
