Equipment ↠ Kobelco ↠ Excavators ↠ 2016 Kobelco SK85CS-3E

2016 Kobelco SK85CS-3E For Sale in North East, Md

Name: 2016 Kobelco SK85CS-3E
Brand: Kobelco
SKU: 88555035
Price: 1 USD
Availability: InStock

❮

❯

/ Save to Watch List

Apply for Financing

Auction Pricing

Auction Info: Starting on 2026-06-23 Click here to place a bid

Ritchie Bros. Auctioneers

Ritchie Bros. Auctioneers Dealer Info

Ritchie Bros. Auctioneers Website

Click here to email Ritchie Bros. Auctioneers.

Click for Phone Number

Machine Info:

Hours:	4490
Serial Number:	LF0806012
Machine Location:	NORTH EAST, MD

Description:

Located in Lane 8 Spot 2 Closing Time: 2026-06-23 04:00:00 PM

From the manufacturer:

Supplied by HeavyEquipmentData.com →

The Kobelco SK85CS-3E is a compact excavator in the 8.5-ton class, designed for construction, utility, landscaping, and site preparation work. It features a short-tail swing design for improved maneuverability in confined spaces, making it suitable for urban job sites and roadside applications. The SK85CS-3E is typically equipped with a diesel engine, hydraulic system, and operator cab or canopy configuration depending on market specification. Common attachments include buckets, hydraulic breakers, and augers. As part of Kobelco's excavator lineup, the SK85CS-3E is used for digging, trenching, grading, and material handling in general earthmoving applications.

Boom/Stick Excavator Option 1
Arm Crowd Force - SAE	8,100 lbs (3,674 kg)
Arm Crowd Force-ISO	8,300 lbs (3,765 kg)
Bucket Digging Force - ISO	16,456 lbs (7,464 kg)
Bucket Digging Force - SAE	14,658 lbs (6,649 kg)
Max Digging Depth	14 ft (4 m)
Max Digging Height	23 ft (7 m)
Max Digging Reach	24 ft (7 m)
Max Dumping Clearance	16 ft (5 m)
Max Reach Along Ground	23 ft (7 m)
Max Vertical Wall Digging Depth	12 ft (4 m)
Min Dumping Clearance	6 ft (2 m)
Minimum swing radius	138 in (350 cm)
Boom/Stick Excavator Option 2
Max Digging Depth	15 ft (5 m)
Max Vertical Wall Digging Depth	13 ft (4 m)
Brakes
Gradeability	70%
Parking brake	Oil disc brake per motor
Travel speed	3 mph (5 kph)
Capacities
Cooling system	2 gal (9 l)
Engine Oil	3 gal (11 l)
Fuel Tank	32 gal (120 l)
Hydraulic oil tank	10 gal (36 l)
Hydraulic system	23 gal (85 l)
Travel reduction	1 gal (3 l)
Cylinders
Bore (Arm)	4 in (10 cm)
Bore (Boom)	4 in (11 cm)
Bore (Bucket)	3 in (8 cm)
Stroke (Arm)	33 in (83 cm)
Stroke (Boom)	36 in (92 cm)
Stroke (Bucket)	29 in (74 cm)
Dimensions
Crawler length	9 ft (3 m)
Ground Clearance	14 ft (4 m)
Height - Top of Cab	9 ft (3 m)
Shoe width	24 ft (7 m)
Tail Swing Radius	6 ft (2 m)
Engine
Bore	3 in (9 cm)
Displacement	133 cu in (2,179 cu cm)
Engine Model	ISUZU AU-4LE2X
Max Torque	155 lbs ft (210 nm)
Net Power	55 hp (41 kw)
Number of Cylinders	4
Power Measured @	2,000 rpm
Stroke	4 in (10 cm)
Torque Measured @	1,800 rpm
Hydraulic System
Hydraulic System Type	Two variable displacement pumps
Max. discharge flow	12 gpm (46 lpm)
Travel circuit	4,260 psi
Operating Specifications
Operating Weight	41,227 lbs (18,700 kg)
Swing Mechanism
Swing Speed	12 rpm
Swing Torque	12,500 lbs ft (16,948 nm)
Undercarriage
Drawbar Pull	17,300 lbs (7,847 kg)
Track Gauge	6 ft (2 m)
